Chapter 2 Media Changer Commands
Persistent Reserve Out Command (5Fh)
Quantum SuperLoader 3 Software Interface Guide 79
Figure 49 Persistent Reserve
Out Descriptor
Figure 50 Persistent Reserve
Out Command
Bit
Byte765 4 3210
0
Operation Code (5Fh)
1
Reserved Service Action
2
Scope Type
3 - 6
Reserved
7 – 8
(MSB)
Parameter List Length (18h)
(LSB)
9
Unused Reserved Flag Link
Field Name Description
Service Action Service actions that require information about persistent reservation and
registrations may require enabling of nonvolatile memory within the logical
unit.
Service action codes available are:
Code Name Description
00h Register Register a reservation key with the device server
01h Reserve Create a persistent reservation using a
reservation key
02h Release Release a persistent reservation
03h Clear Clear all reservation keys and all persistent
reservations
