Chapter 2 Media Changer Commands
Mode Sense (6) / (10) Command (1Ah/ 5Ah)
Quantum SuperLoader 3 Software Interface Guide 57
4-5
(MSB)
Number of Medium Transport Elements
(LSB)
6-7
(MSB)
First Storage Element Address
(LSB)
8-9
(MSB)
Number of Storage Elements
(LSB)
10-11
(MSB)
First Import/Export Element Address
(LSB)
12-13
(MSB)
Number of Import/Export Address
(LSB)
14-15
(MSB)
First Data Transfer Element Address
(LSB)
16-17
(MSB)
Number of Data Transfer Elements
(LSB)
18-19
Reserved
Bit
Byte 7 6 5 4 3 2 1 0
