Chapter 2 Media Changer Commands
Mode Sense (6) / (10) Command (1Ah/ 5Ah)
Quantum SuperLoader 3 Software Interface Guide 53
TapeAlert Page (1Ch) 2
The SuperLoader 3 supports the TapeAlert Page that is used to set/change
the supported
TapeAlert configuration options. Use the MODE SENSE
command to read the settings of the
TapeAlert page.
Figure 38 TapeAlert Page
Format Descriptor
Additional Page
Length
This field indicates the number of bytes in the page.
Note that this value does not include bytes 0 and 1.
The length is returned on
MODE SENSE and must
subsequently be set to the same value when
performing
MODE SELECT.
Bit
Byte76543210
0
PS (0) 0 Page Code (1Ch)
1
Additional Page Length (0Ah)
2
Perf Reserved DExcpt Test Rsvd LogErr
3
Reserved MRIE
4 - 7
(MSB)
Interval Timer
(LSB)
8 - 11
MSB)
Report Count/Test Flag Number
(LSB)
Field Name Description
