Chapter 2 Media Changer Commands
Mode Sense (6) / (10) Command (1Ah/ 5Ah)
Quantum SuperLoader 3 Software Interface Guide 52
Table 25 Mode Sense Data
Header
Mode Sense Mode Pages2
The following figure depicts the variable length page descriptor.
Figure 37 Mode Sense Page
Descriptor
Descriptions of the MODE SENSE page descriptor fields are provided in
the following table. Detailed descriptions of each of the
MODE SENSE
Pages
follow.
Table 26 Mode Sense Page
Descriptor
Field Name Description
Mode Sense
Data Length
This field specifies the length (in bytes) of the
MODE
SENSE
data that is available to be transferred during
the
DATA IN phase. Note that the Mode Sense Data
Length
does not include itself.
Block
Descriptor
Length
This field specifies the length (in bytes) of all of the
block descriptors. This value will be 0, indicating no
Block Descriptors were sent.
Bit
Byte76543210
0
PS 0 Page Code
1
Additional Page Length
2
Page Defined or Vendor Specific Parameter Bytes
Field Name Description
PS
Parameters Savable. When 0, the supported
parameters cannot be saved (savable pages are not
supported). When set to 1, it indicates that the page
can be saved in nonvolatile memory by the media
changer.
