Mode Sense (6) / (10) Command (1Ah/ 5Ah)
Quantum SuperLoader 3 Software Interface Guide 51
Figure 35 Mode Sense (6)
Data Header
Figure 36 Mode Sense (10)
Data Header
Bit
Byte76543210
0
Mode Sense Data Length
1
Reserved
2
Reserved
3
Block Descriptor Length (0)
Bit
Byte76543210
0 - 1
(MSB)
Mode Sense Data Length
(LSB)
2
Reserved
3
Reserved
4 - 5
Reserved
6 - 7
(MSB)
Block Descriptor Length (0)
(LSB)
