Chapter 2 Media Changer Commands
Mode Sense (6) / (10) Command (1Ah/ 5Ah)
Quantum SuperLoader 3 Software Interface Guide 49
Figure 34 Mode Sense (10)
Command Descriptor Block
Table 24 Mode Sense
Command Descriptor Block
Bit
Byte7654321 0
0
Operation Code (5Ah)
1
Logical Unit Number Rsv’d DBD Reserved
2
PC Page Code
3
SubPage
4 – 6
Reserved
7 - 8
(MSB)
Allocation Length
(LSB)
9
Unused Reserved Flag Link
Field Name Description
DBD
Disable Block Descriptors. This field is ignored. This device does not return
a block descriptor regardless of this field.
PC
Page Control. The Page Control field indicates the type of page parameter
values to be returned to the host:
PC Type of Parameter Values
00 Report Current Values
01 Report Changeable Values
10 Report Default Values
