Chapter 2 Media Changer Commands
Mode Sense (6) / (10) Command (1Ah/ 5Ah)
Quantum SuperLoader 3 Software Interface Guide 48
Mode Sense (6) / (10) Command (1Ah/ 5Ah)
The MODE SENSE command allows the media changer to report its
current or changeable configuration parameters to the host. It is a
complementary command to
MODE SELECT.
The command descriptor block for the 6-byte
MODE SENSE (1Ah) is
shown below. An illustration of the command descriptor block for the 10-
byte
MODE SENSE (5Ah) follows on the next page.
Figure 33 Mode Sense (6)
Command Descriptor Block
The MODE SENSE (10) command returns descriptor data in a different
format than
MODE SENSE (6).
Bit
Byte76543210
0
Operation Code (1Ah)
1
Logical Unit Number Rsv’d DBD Reserved
2
PC Page Code
3
SubPage
4
Allocation Length
5
Unused Reserved Flag Link
