Mode Select (6) / (10) Command (15h / 55h)
Quantum SuperLoader 3 Software Interface Guide 46
Figure 31 Mode Select
Parameter
Table 22 Mode Select
Parameter Block
Mode Page Descriptors 2
Following the MODE SELECT command’s Mode Parameter Block
Descriptor
are the MODE SELECT pages, each of which sets a different
device parameter. Each mode page has a 2-byte header that identifies the
page code and indicates the number of bytes in that page.
Bit
Byte76543210
0
Reserved
1 - 3
(MSB)
Number of Blocks
(LSB)
4
Reserved
5 - 7
(MSB)
Block Length
(LSB)
Field Name Description
Number of
Blocks
This field is sent as 0. It is not applicable to media
changer devices.
Block Length This field is sent as 0. It is not applicable to media
changer devices.
