Chapter 2 Media Changer Commands
Mode Select (6) / (10) Command (15h / 55h)
Quantum SuperLoader 3 Software Interface Guide 43
Mode Parameter List 2
The following figure shows the format of the Mode Parameter List that is
passed by the initiator to the media changer during the command’s
DATA
OUT
phase.
Figure 27 Mode Select (6)
Mode Parameter List
Figure 28 Mode Select (10)
Mode Parameter List
Table 20 Mode Select
Parameter List
Bit
Byte 76543210
0 - 3
Mode Parameter Header
4 - 11
Mode Parameter Block Descriptor (Optional)
4 – 11 or
12 - n
Page(s) (Optional)
Bit
Byte 76543210
0 - 7
Mode Parameter Header
8 - 15
Mode Parameter Block Descriptor (Optional)
8 - n
or 16 - n
Page(s) (Optional)
Field Name Description
Mode Parameter
Header
4 or 8 bytes in length, contains information about
the remainder of the
Parameter List and is always
present.
