Mode Select (6) / (10) Command (15h / 55h)
Quantum SuperLoader 3 Software Interface Guide 42
Figure 26 Mode Select (10)
Command Descriptor
Table 19 Mode Select (6)/(10)
Command Descriptor
2 – 3
Reserved
4
Parameter List Length
5
Unused (00) Reserved Flag Link
Bit
Byte76543210
0
Operation Code (55h)
1
Logical Unit Number PF Reserved SP (0)
2 – 6
Reserved
7 - 8
Parameter List Length
9
Unused (00) Reserved Flag Link
Field Name Description
PF
Page Format. The Page Format bit indicates that the
data sent by the host after the
MODE SELECT header
and block descriptors complies with the definition of
pages in the SCSI-2 specification. The SCSI-1 format
will not be implemented so this bit must be set to 1. It
is an
ILLEGAL REQUEST to have page parameters
while the PF bit is 0.
SP
Save Parameters. Must be 0. If set, this bit instructs the
SuperLoader 3 to save all savable pages, and this is
not supported.
Bit
Byte76543210
