Chapter 2 Media Changer Commands
Log Sense Command (4Dh)
Quantum SuperLoader 3 Software Interface Guide 37
Device Status Page (3Eh)2
The Device Status Page describes the current status of the media changer.
Figure 22 Device Status Log
Sense Header
TSD Target Save Disable not supported, always 1.
ETC
Enable Threshold Comparison. Threshold checking is not supported on this
page. Always set to 0.
TMC
Threshold Met Criteria. Always 0.
LP
List Parameter. Always set to 0.
Parameter
Length
The number of bytes to follow (0Ch).
Time Stamp The Time Stamp is represented as number of power cycles and total power
on hours.
Source
Element/
Destination
Element
These fields report the element addresses that were involved in the failure.
These fields will be zero (0) if the failure did not involve a move command.
Bit
Byte76543210
0
Reserved Page Code (3Eh)
1
Reserved
2 - 3
(MSB)
Page Length
(LSB)
Field Name Description
