Chapter 2 Media Changer Commands
Log Sense Command (4Dh)
Quantum SuperLoader 3 Software Interface Guide 33
Figure 18 Hard/Soft Move
Error Statistics Format
Bit
Byte76543210
0
Reserved Page Code (31h)
1
Reserved
2 - 3
(MSB)
Page Length (22h)
(LSB)
4-5
(MSB)
Servo Hard Errors
(LSB)
6-9
(MSB)
Drive Soft Error
(LSB)
10-13
(MSB)
Left Magazine Soft Error
(LSB)
14-17
(MSB)
Right Magazine Soft Error
(LSB)
18-21
(MSB)
Mail Slot Soft Error
(LSB)
22-25
(MSB)
Rotation Recovery Actions
(LSB)
