Chapter 2 Media Changer Commands
Inquiry Command (12h)
Quantum SuperLoader 3 Software Interface Guide 18
There are three different Identification Descriptors returned, in numerical
order of the
Identifier Type. Each Identification Descriptor takes the
following form:
Figure 8 Identifier Descriptor
Table 4 Identifier Descriptor
Field Descriptions
Bit
Byte76543210
0
Reserved Code Set
1
Reserved Association Identifier Type
2
Reserved
3
Identifier Length (n-3)
4 - n
Identifier
Field Name Field Description
Code Set Indicates the type of data to be found in the
Identifier field. A value of 1 indicates binary data. A
value of 2 indicates ASCII data.
Association Indicates whether the
Identifier is associated with
the logical unit or the port. Always contains a 0,
indicating the
Identifier is associated with the logical
unit.
Identifier Type Type of identifier.
Value Description
1 Concatenation of the Vendor Name,
Product ID, and unit serial number
2 Canonical form of the IEEE Extended
Unique Identifier, 64 bit (EIU-64)
3 FC-PH Name_Identifier
