Chapter 2 Media Changer Commands
Inquiry Command (12h)
Quantum SuperLoader 3 Software Interface Guide 15
Vital Product Data Page 2
The following sections describe the Vital Product Data Pages for the
system.
Add16 This devices supports 16-bit wide SCSI addresses.
RelAdr This device does not support relative addressing.
WBUS16 This device supports 16-bit wide data transfers.
Sync Refer to the drive interface guide to find out if synchronous
data transfers are supported.
Linked This device does not support linked commands.
CmdQue* This device does not support command queueing.
Vendor Identification
(QUANTUM)
Identification of vendor.
Product Identification
(UHDL)
Identification of the product
Product Revision
Level (xxxx)
This field contains 4 bytes of ASCII hex data that provides the
media changer’s firmware revision level.
Language This field indicates the language used for the front panel and
On-board Remote Management.
Image Type This field indicates the type of firmware image required when
downloading a new image. SuperLoader 3 reports a 2.
Firmware Personality Numeric indicator of firmware personality. Note that when
set to 4, this indicates OEM family.
Firmware
Subpersonality
Set to 2, indicating standard SCSI device firmware.
Vendor-Specific
Subtype
Identification of product.
* The BQue and CmdQue bits are set on HP drives, even though these options are not
supported. It is necessary to set these bits for Adaptec® HBAs to support Ultra 320.
These values will vary depending on the drive type in the autoloader.
Field Name Description
