Write Buffer Command (3Bh)
Quantum SuperLoader 3 Software Interface Guide 140
Write Buffer Command (3Bh)
The WRITE BUFFER command is used with READ BUFFER as a diagnostic
function and for downloading and updating microcode (firmware).
Figure 83 Write Buffer
Descriptor
Table 64 Write Buffer
Command Data
Bit
Byte765 4 3210
0
Operation Code (3Bh)
1
Logical Unit Number Reserved Mode
2
Buffer ID
3 - 5
(MSB)
Buffer Offset
(LSB)
6 - 8
(MSB)
Transfer Length
(LSB)
9
Unused Reserved Flag Link
Field Description
Mode The media changer supports the following values within the field. If any other
value is set, the media changer terminates the command with
CHECK
CONDITION
status and an ILLEGAL REQUEST sense key set.
