Chapter 2 Media Changer Commands
Request Sense Command (03h)
Quantum SuperLoader 3 Software Interface Guide 129
2A 05 Registrations Preempted
3B 12 Magazine Removed
3B 13 Magazine Inserted
3F 01 Microcode has been Changed
3F 05 Device Identifier Changed
0Bh
COMMAND
ABORTED
08 00 Command Aborted - LUN Communication
Failure
08 01 Command Aborted - LUN Communication
Time-out
3F 00 Operating Conditions have Changed
3F 0F Echo Buffer Overwritten
43 00 Message Error
44 80 Unexpected Selection Interrupt
44 82 Command Complete Sequence Failure
44 83 SCSI Chip, Gross Error/ Illegal – Command
Status
44 84 Unexpected/Unexplained Residue Count in
Transfer Register
44 87 Disconnect/ SDP Sequence Failed
45 00 Select/Reselect Failure
47 00 SCSI Parity Error (check SCSI bus configuration
and connections)
48 00 IDE Message Error
49 00 Invalid Message Error
4A 00 Command Phase Error
4B 00 Data Phase Error
Sense Key ASC ASCQ Description
