Chapter 2 Media Changer Commands
Read Element Status Command (B8h)
Quantum SuperLoader 3 Software Interface Guide 110
Data Transfer Element
Descriptor 2
Figure 65 defines the data transfer element descriptor.
Figure 65 Data Transfer
Element Descriptor
IMPEXP When set to 1 it indicates that the unit of media in the
import/export element was placed there by an
operator. When set to 0, it indicates that it was placed
there by the medium transport element. When the
Except bit is 1, the value of the IMPEXP bit is invalid.
NOTE: For fields not defined in this table, see table 49
on page 106.
Bit
Byte 7 65 4 3210
0-1
Element Address
2
Reserved Access Except RSVD Full
3
Reserved
4
Additional Sense Code
5
Additional Sense Code Qualifier
6
Not BUS
(0)
RSVD ID
Valid
LU
Valid
RSVD Logical Unit Number
7
SCSI BUS Address
8
Reserved
9
SVALID Invert Reserved
Field Name Description
