Chapter 2 Media Changer Commands
Read Element Status Command (B8h)
Quantum SuperLoader 3 Software Interface Guide 107
Storage Element
Descriptor 2
Figure 63 defines the storage element descriptor.
Figure 63 Storage Element
Descriptor
Bit
Byte 7 65 4 3210
0-1
Element Address
2
Reserved Access Except RSVD Full
3
Reserved
4
Additional Sense Code
5
Additional Sense Code Qualifier
6-8
Reserved
9
SVALID Invert Reserved
10-11
Source Storage Element Address
•••
(36 bytes)
Primary Volume Tag Information
(field omitted if PVOLTAG=0)
•••
(1 byte)
Reserved Code Set
(1 byte)
Reserved Identifier Type
(1 byte)
Reserved
(1 byte)
Identifier Length
