Chapter 2 Media Changer Commands
Read Element Status Command (B8h)
Quantum SuperLoader 3 Software Interface Guide 105
Medium Transport
Element Descriptor 2
Figure 62 defines the medium transport element descriptor.
Figure 62 Medium Transport
Element Descriptor
Bit
Byte 7 6 5 4 3 2 1 0
0-1
Element Address
2
Reserved Except RSVD Full
3
Reserved
4
Additional Sense Code
5
Additional Sense Code Qualifier
6-8
Reserved
9
SVALID Invert
(0)
Reserved
10-11
Source Storage Element Address
•••
(36 bytes)
Primary Volume Tag Information
(field omitted if PVOLTAG=0)
•••
(1 byte)
Reserved Code Set
(1 byte)
Reserved Identifier Type
(1 byte)
Reserved
(1 byte)
Identifier Length
