User's Guide

Chapter 2 Media Changer Commands
Read Element Status Command (B8h)
Quantum SuperLoader 3 Software Interface Guide 104
Figure 61 Data
Each element descriptor includes the element address and status flags; it
may also contain sense code information as well as other information
depending on the element type (see Medium Transport Element
Descriptor through “Data Transfer Element Descriptor” on page 110).
8-y
(MSB)
Element descriptor(s)
(LSB)
Field Name Description
Element
Type Code
Indicates the element type (see table 47
) reported by
this page.
PVOLTAG When set to 1, indicates that the
Primary Volume Tag
Information
field is present in each of the following
element descriptor blocks. A value of zero indicates
that these bytes are omitted from the element
descriptors that follow.
AVOLTAG This field is sent as 0. Alternate volume tag
information is not supported.
Element
Descriptor
Length
Indicates the number of bytes in each element
descriptor.
Byte Count
Of
Descriptor
Data
Available
Indicates the number of bytes of element descriptor
data available for elements of this element type
meeting the request in the
CDB. This value shall not be
adjusted to match the
Allocation Length available.
Bit
Byte 7 6 5 4 3210
