Chapter 2 Media Changer Commands
Position to Element Command (2Bh)
Quantum SuperLoader 3 Software Interface Guide 92
Position to Element Command (2Bh)
The POSITION TO ELEMENT command shall position the Medium
Transport Address
element such that further motion of the Medium
Transport Address
element is unnecessary to execute an appropriate
MOVE MEDIUM command between the Medium Transport Address element
and the
Destination Address element.
Figure 52 Position to Element
Descriptor
Bit
Byte765 43210
0
Operation Code (2Bh)
1
Logical Unit Number Reserved
2-3
(MSB)
Medium Transport Address
(LSB)
4-5
(MSB)
Destination Address
(LSB)
6-7
Reserved
8
Reserved Invert
(0)
9
Unused Reserved Flag Link
