Chapter 3 Installing Your Tape Drive
Configuring and Installing an Internal Tape Drive with Fibre Channel Interface
SDLT 600 Product Manual 55
Table 29 4-Pin Power
Connector Pin Assignments
Table 30 8-Pin Loader
Connector Pin Assignments
Configuring and Installing an Internal Tape Drive with Fibre
Channel Interface 3
This section provides information for configuring and installing a tape
drive with the Fibre Channel interface into a system.
Fibre Channel Introduction 3 Fibre Channel is the name of an integrated set of standards developed by
the American National Standards Institute (ANSI). The intention of the
Fibre Channel specification is to develop a practical, inexpensive, yet
expandable means of quickly transferring data between workstations,
mainframes, supercomputers, desktop computers, storage devices,
display terminals, and other peripherals.
Pin Number Signal Name
1 +12 VDC
2 Ground (+12V return)
3 Ground (+5V return)
4 +5 VDC
Signal Name Pin Number Pin Number Signal Name
Ground 1 5 SEND_TO_LOADER_H
REC_FROM_LOADER_H 2 6 SEND_TO_LOADER_L
REC_FROM_LOADER_L 3 7 Ground
Ground 4 8 LOADER_PRESENT_L
