3URGXFW 0DQXDO 3URGXFW 0DQXDO 3URGXFW 0DQXDO 3URGXFW 0DQXDO 7DSH 'ULYH 6'/7 3 $
SDLT 600 Product Manual, 81-81184-03 A01, December 2005, Made in USA. Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this publication from time to time without notice. COPYRIGHT STATEMENT Copyright 2005 by Quantum Corporation. All rights reserved. Your right to copy this manual is limited by copyright law.
Contents Preface Chapter 1 xi Tape Drive Product Information 1 Overview ........................................................................................................................... 2 Product Features............................................................................................................... 3 Tape Drive Technology ................................................................................................... 4 Laser Guided Magnetic Recording.......................
Chapter 2 SDLT 600 Tape Drive Specifications 13 Product Specifications ................................................................................................... 13 Host Interface........................................................................................................... 13 Physical Interface .................................................................................................... 16 Physical Dimensions and Weights .......................................................
Contents Configuring and Installing an Internal Tape Drive with Fibre Channel Interface .................................................................................................... 55 Fibre Channel Introduction ................................................................................... 55 Secure the Tape Drive............................................................................................. 58 Connect the Power .....................................................................
Electromagnetic Field Specifications ........................................................................... 84 Electromagnetic Emissions .................................................................................... 84 Electromagnetic Interference Susceptibility........................................................ 84 Immunity and ESD Limits ..................................................................................... 85 Acoustic Noise Emissions .........................................
Figures Figure 1 SDLT 600 Tape Drive Systems ....................................................... 3 Figure 2 SDLT 600 Tape Drive Modular Design......................................... 7 Figure 3 Multiple Layers Comprise Super DLTtape II Media ................ 33 Figure 4 Super DLTtape II Data Cartridge ................................................ 34 Figure 5 Detail of the Empty SCSI ID Jumper Block ................................
Figures Figure 15 Cabling Options for the SCSI Tape Drive Tabletop Model ..... 62 Figure 16 AC Power Cord Connector Types............................................... 64 Figure 17 Connecting the Fiber Optic Cable to a Tabletop Fibre Channel Tape Drive ................................................................... 66 Figure 18 AC Power Cord Connector Types............................................... 67 Figure 19 Front Panel LEDs .....................................................................
Tables SDLT 600 Product Manual Table 1 SDLT 600 Tape Drive Interface Versions Speeds and Options .......... 14 Table 2 SDLT 600 Tape Drive Interface............................................................... 16 Table 3 SDLT 600 Tape Drive Physical Dimensions.......................................... 16 Table 4 SDLT 600 Tape Drive Shipping Weight ................................................ 17 Table 5 SDLT 600 Tape Drive Storage Capacity ................................................
Tables SDLT 600 Product Manual Table 18 Temperature and Humidity Specification ............................................ 31 Table 19 Tape Drive Storage and Shipment Specifications ................................ 31 Table 20 Super DLTtape II Media Specifications ................................................. 32 Table 21 Super DLTtape II Media Shipping Limits............................................. 34 Table 22 Super DLTtape II Media Operating Limits......................................
Preface This document serves as an easy-to-use information source and product catalog to familiarize Quantum customers and systems professionals with the SDLT 600 tape drive system. The SDLT 600 tape drive is an extension of the Quantum Digital Linear Tape (DLT®) product family. Audience The primary audience for this document consists of end users installing and using the tape drive. The information in this document applies to the internal tape drive, the library tape drive, and the tabletop tape drive.
Preface • Chapter 1, Tape Drive Product Information, provides an overview of the tape drive system, including features, tape drive technology, tape drive design, and diagnostic tools. • Chapter 2, SDLT 600 Tape Drive Specifications, provides the product, functional, environmental, and recording media specifications of the tape drive. • Chapter 3, Installing Your Tape Drive, describes warranty, safety, SCSI settings, and all the steps you need to follow to install the tape drive.
Preface Related Documents SDLT 600 Product Manual • Tape Drive — Refers to just the tape drive and does not include the cartridge. • Right side of the tape drive — Refers to the right side as you face the component being described. • Left side of the tape drive — Refers to the left side as you face the component being described. • Power cycle — Means to turn the tape drive or system on, then turn them off (or off, then on).
Preface Document No. Document Title Document Description 81-81220-xx SDLT 600 User Reference Guide Provides instructions on how to install, run the tape drive, hardware, performance, environment, shock and vibration, and regulatory specifications for the tape drive 81-81305-xx SDLT 600 Quick Start Guide Provides brief instructions on how to install the tape drive 81-81202-xx SDLT 600 Fibre Channel Interface Guide Provides Fibre Channel command information specific to the tape drive.
Preface See the appropriate documentation for information on the tape drive and cartridges. SCSI Standards 0 Copies of the approved version of the SCSI standards may be obtained from: Global Engineering Documents 15 Inverness Way, East Englewood, CO 80112 (800) 854-7179 or (303) 397-2740 Contacts Quantum company contacts are listed below.
Preface 0 Customer Support The Quantum Customer Support Department provides a 24-hour help desk that can be reached at: North/South America: (949) 725-2100 or (800) 284-5101 Asia/Pacific Rim: (International Code) + 61 7 3839 0988 Europe/Middle East/Africa: (International Code) + 44 (0) 1256 848748 Send faxes for the Customer Support Department to: North/South America: (949) 725-2176 Asia/Pacific Rim: (International Code) + 61 7 3839 0955 Europe/Middle East/Africa: (International Code) + 44 (0)
Chapter 1 Tape Drive Product Information 1 This chapter describes the features of the Quantum SDLT 600 tape drive system. This chapter covers the following topics: • Overview describes basic features of the system. • Product Features lists key features of the SDLT 600 tape drives. • Tape Drive Technology includes photographs of the tape drive, and introduces important basic features. • Modular Design introduces tape drive components such as the tape heads, media, data cartridge, and host interface.
Chapter 1 Tape Drive Product Information Overview Overview 1 The Quantum SDLT 600 tape drive system is a highly scalable tape drive designed for multiple product generations. It is a follow-on to the DLT product family. The SDLT 600 tape drive system comprises both the tape drive and the data cartridge. The system is available in three models: a tabletop (or external) unit, an internal unit for server installation, and a library model for installing in tape automation systems.
Chapter 1 Tape Drive Product Information Product Features Figure 1 SDLT 600 Tape Drive Systems Internal model Tabletop model Product Features 1 The SDLT 600 tape drive system offers the following product features: • A streaming tape drive that uses half-inch wide Super Digital Linear Tape (Super DLTtape II) media. • A standard 5.25-inch full-height form factor to simplify integration into system and tape library solutions.
Chapter 1 Tape Drive Product Information Tape Drive Technology • Backward read compatibility for SDLT 220 and SDLT 320 tape drive formats with the Super DLTtape I data cartridge type; and the DLT VS160 tape drive format with DLTtape® VS1 data cartridge type. • DLTSage iTalk (and Pocket DLTSage iTalk)—Infrared (wireless) interface that provides a remote testing base allowing customers and integrators to access system diagnostic information from the front of the SDLT 600 tape drive system.
Chapter 1 Tape Drive Product Information Tape Drive Technology 1 Pivoting Optical Servo (POS) is a Quantum-invented, optically-encoded Pivoting Optical Servo servo system, that combines high-density magnetic read/write data recording with laser servo guiding. The POS provides high-duty-cycle applications, which decreases cost and increases user convenience.
Chapter 1 Tape Drive Product Information Modular Design extensive duty-cycle environments found in high-end and automation environments. This mechanism engages the tape leader upon data cartridge load and disengages it upon data cartridge unload. It uses a solid metal pin attached to the drive leader to link with molded clips permanently attached to the tape leader inside the data cartridge. The Positive Leader Link design makes the buckling of Super DLTtape media a totally reliable mechanical process.
Chapter 1 Tape Drive Product Information Modular Design Figure 2 SDLT 600 Tape Drive Modular Design TCM FPM Data Cartridge DCM EIM ICM EIM HIM Note: Data Control Module Despite the deliberate modularity of each module, with the exception of the FPM, individual users should not swap modules. The FPM is the only module that is field replaceable. Customer adjustments to the TCM, DCM, or EIM will void the tape drive’s warranty.
Chapter 1 Tape Drive Product Information Modular Design • Tape heads. In addition to its mechanical components, the DCM also contains printed circuit boards that control the functions of the DCM and the tape heads. Tape Control Module 1 The Tape Control Module (TCM) implements the functions required to buckle and unbuckle the tape and control the tape motion.
Chapter 1 Tape Drive Product Information Modular Design Data Cartridge Receiver 1 On tape insertion, the data cartridge receiver assembly guides the tape into its operating position, opens the data cartridge door, unlocks the data cartridge brakes, engages the data cartridge drive motor, and secures the tape for operation. On tape ejection, the data cartridge receiver assembly reverses the process and automatically ejects the tape a fixed distance from the front of the tape drive.
Chapter 1 Tape Drive Product Information Quantum Diagnostics Tools The EIM consists of two major boards: the Integrated Controller Module (ICM), and a separate Host Interface Module (HIM). The ICM contains the main controller and servo microprocessor, the custom-designed SDLT ASICs, and the cache memory while the HIM implements the interface between the host system and the tape drive.
Chapter 1 Tape Drive Product Information TapeAlert Refer to the following procedure to access these tools. 1 Go to the Quantum Web site: http://www.quantum.com. 2 Click SERVICE AND SUPPORT in the upper menu bar. This opens the Service and Support window. 3 Explore the various pages that comprise Service and Support until you find what you need. New tools and utilities get added frequently, so check back often. TapeAlert 1 SDLT 600 tape drives are delivered with TapeAlert™ features built in.
Chapter 1 Tape Drive Product Information TapeAlert For more information about MAM, see the SDLT 600 SCSI Interface Guide (81-81200-xx) or the SDLT 600 Fibre Channel Interface Guide (81-81202-xx). For more information about DLTSage, see the DLTSage Implementation Guide (81-81201-xx).
Chapter 2 2 SDLT 600 Tape Drive Specifications This chapter describes various specifications that apply to the Quantum SDLT 600 tape drive system: • Product Specifications provides tape drive specifications • Functional Specifications provides functional specifications for the tape drive • Environmental Specifications provides environmental specifications for operating the tape drive • Recording Media Specifications provides media specifications for Super DLTtape II data cartridges.
Chapter 2 SDLT 600 Tape Drive Specifications Product Specifications Table 1 SDLT 600 Tape Drive Interface Versions Speeds and Options Interface Versions Speeds Protocol Options Fibre Channel • 100 MB/second • 200 MB/second • • • • • • • Ultra 160 • 160 MB/second maximum burst speed ** Class3 Connect to N port, NL port, FL port FC-MI FC-AL-2 FCP-2 FC-FS SCSI-3 (SAM-2, SPC-2, or SSC) • Multi-mode Single-Ended (MSE) provides one of two differential senses: - Low Voltage Differential (LVD) running
Chapter 2 SDLT 600 Tape Drive Specifications Product Specifications The tape drive automatically senses the SCSI bus mode and switches between LVD and SE accordingly. Although the tape drive defaults to LVD, it switches to SE if the SCSI bus operates in SE mode. For example, if the SCSI controller card is SE (or multimode set to SE), the tape drive automatically switches to SE mode. Also, if any device on the SCSI bus is SE, the entire bus switches to SE, including the tape drive.
Chapter 2 SDLT 600 Tape Drive Specifications Product Specifications Physical Interface 2 The SDLT 600 tape drive has the interfaces shown in table 2 available from the back panel (per type, per port).
Chapter 2 SDLT 600 Tape Drive Specifications Product Specifications Depth Internal Version Library Version 203.20 mm (8.00 in.) from back of front bezel 203.20 mm (8.00 in.) from back of front bezel 215.40 mm (8.48 in.) including front bezel 212.22 mm (8.36 in.) including front bezel Tabletop Version 320.04 mm (12.60 in.) Mounting hole pattern for the bottom and sides of the system is industry standard. Table 4 shows the weights of the SDLT 600 tape drive.
Chapter 2 SDLT 600 Tape Drive Specifications Product Specifications Storage Capacity 2 Table 5 provides native and compressed capacity ranges for the Super DLTtape II data cartridge: Table 5 SDLT 600 Tape Drive Storage Capacity Mode Capacity Native Storage Capacity 300 GB Compressed Storage Capacity 600 GB (2:1 compression ratio) In accordance with industry practice, a typical compression ratio of 2:1 is quoted.
Chapter 2 SDLT 600 Tape Drive Specifications Product Specifications Maximum Data Transfer 2 Rate Table 7 Maximum Data Transfer Rates Table 7 shows the maximum sustained (and burst) data transfer rates for the SDLT 600 tape drive.
Chapter 2 SDLT 600 Tape Drive Specifications Product Specifications Head Life and MTBF 2 The projected mean time between failures (MTBF) for the overall SDLT 600 tape drive system is 250,000 hours, not including the heads. Head life is a minimum of 30,000 tape motion hours and an average of 50,000 media motion hours. Note: Media Durability The manufacturer does not warrant that predicted MTBF is representative of any particular unit installed for customer use. Actual figures vary from unit to unit.
Chapter 2 SDLT 600 Tape Drive Specifications Functional Specifications Table 9 Loading and Unloading the Data Cartridge (Maximum) Positive Engagement Tape Leader Buckling 2 Mechanism Super DLTtape II Data Cartridge Data cartridge load/unload cycles* 5,000 Media insertions** 20,000 * A load/unload cycle is when a data cartridge is inserted into the receiver, loaded to BOT, calibrated, and then unloaded. ** An insertion is when a data cartridge is inserted into the receiver and then unloaded.
Chapter 2 SDLT 600 Tape Drive Specifications Functional Specifications Table 10 SDLT 600 Tape Drive Performance Data Feature SDLT 600 Tape Drive Drive Read/Write Transfer Rate* 36 MB/second, native 72 MB/second, compressed Tracks 40 logical tracks 640 physical tracks Track Density 1502 tracks per inch (tpi) Linear Bit Density 233 Kbits per inch (Kbpi) Read/Write Tape Speed 108 inches per second (ips) Rewind Tape Speed 160 ips Linear Search Tape Speed 160 ips Average Rewind Time** 77 secon
Chapter 2 SDLT 600 Tape Drive Specifications Functional Specifications Shock and Vibration Specifications Table 11 Non-operating Shock Specifications (Unpackaged) Table 12 Non-Operating Shock Specifications (Packaged, Drop) Table 13 Non-Operating Vibration Specifications (Unpackaged) SDLT 600 Product Manual The following tables provide non-operating and operating shock and 2 vibration specifications for the SDLT 600 tape drive system.
Chapter 2 SDLT 600 Tape Drive Specifications Functional Specifications Vibration (Unpackaged) Table 14 Non-Operating Vibration Specifications (Packaged) Application X,Y,Z axes Type Random Frequency Range 10 to 500 Hz Acceleration Level 2.0 G PSD Envelope 0.008 G2/Hz Application X,Y,Z axes Sweep rate = 60 minutes/axis Vibration (Packaged) Type Random Frequency Range Truck Profile* (0.5 Grms) Air Profile* (1.
Chapter 2 SDLT 600 Tape Drive Specifications Functional Specifications Table 15 Operating Shock and Vibration Specifications Shock Pulse Shape ½ sine pulse Peak Acceleration 10 G Duration 10 ms Application X,Y,Z axes, twice in each axis (once in each direction) Vibration Current and Power Requirements Type Sine Sweep Frequency Range 5 to 500 to 5 Hz Upward and downward sweep Acceleration Level 0.25 G 0.
Chapter 2 SDLT 600 Tape Drive Specifications Functional Specifications (The power drawn in these two modes is similar enough that they are listed together.) Note: In table 16 and table 17, the current and DC power values pertain to the internal tape drive, while the AC power values apply to the tabletop tape drive.
Chapter 2 SDLT 600 Tape Drive Specifications Functional Specifications Mode Max for SDLT 600 tape drive Modes9 5 V Current (A) MaxPk1 MaxMean2 Typ3 n/a 5.3 n/a 12 V Current (A) MaxPk1 MaxMean2 Typ3 DC Power (W) Max4 Typ5 AC Power (W) Max6 Typ7 n/a 30 70 0.9 n/a n/a n/a 1. The Max-Peak value represents short current spikes drawn for durations of < 50ms. On the 12V supply, the peaks correspond to the pulse-width-modulated switching of the motors.
Chapter 2 SDLT 600 Tape Drive Specifications Functional Specifications Table 17 Current and Power Requirements (Fibre Channel Interface) Mode 5 V Current (A) MaxPk1 MaxMean2 Typ3 Standby/Idle 3.5 3.5 3.1 0.2 0.1 0.1 18 17 n/a n/a Media Loading/ Unloading 5.4 4.4 4.4 2.7 0.7 0.7 30 30 n/a n/a 600 Write– Motor Start8 4.6 4.3 4.2 1.3 0.3 0.3 25 25 n/a n/a 600 Write– Streaming 5.9 5.6 5.5 0.7 0.5 0.
Chapter 2 SDLT 600 Tape Drive Specifications Functional Specifications Mode Max for SDLT 600 tape drive Modes9 5 V Current (A) MaxPk1 MaxMean2 Typ3 n/a 5.6 n/a 12 V Current (A) MaxPk1 MaxMean2 Typ3 DC Power (W) Max4 Typ5 AC Power (W) Max6 Typ7 n/a 33 n/a 0.7 n/a n/a n/a 1. The Max-Peak value represents short current spikes drawn for durations of < 50ms. On the 12V supply, the peaks correspond to the pulse-width-modulated switching of the motors.
Chapter 2 SDLT 600 Tape Drive Specifications Environmental Specifications SDLT 600 Tape Drive System Recording Method 2 The SDLT 600 tape drive system uses the Partial Response Maximum Likelihood (PRML) 32/33 encoding method for reading/writing SDLT 600 tape drive format. It uses the same algorithmm for reading SDLT 220, SDLT 320, and the DLT VS160 tape drive formats.
Chapter 2 SDLT 600 Tape Drive Specifications Environmental Specifications Temperature and Humidity 2 The ambient operating environment for the tape drive may not exceed the limits shown in table 18. (The specifications shown in the table are valid for both the internal and tabletop tape drives.
Chapter 2 SDLT 600 Tape Drive Specifications Recording Media Specifications Relative Humidity 10 to 95% (noncondensing) 10 to 95% (noncondensing) Humidity Gradient 10%/hour 10%/hour Note: Altitude These specifications apply to the tape drive only. Media specifications are listed in Recording Media Specifications.
Chapter 2 SDLT 600 Tape Drive Specifications Recording Media Specifications Media Structure Figure 3 Multiple Layers Comprise Super DLTtape II Media 2 Super DLTtape II media comprises several layers, as shown in figure 3.
Chapter 2 SDLT 600 Tape Drive Specifications Recording Media Specifications Physical Data Cartridge 2 A durable plastic case encloses the Super DLTtape II media, as shown in figure 4. Figure 4 Super DLTtape II Data Cartridge Media Shipping, Operating, and Storage 2 Specifications Table 21 Super DLTtape II Media Shipping Limits SDLT 600 Product Manual The optimum media shipping conditions are described in table 21.
Chapter 2 SDLT 600 Tape Drive Specifications Recording Media Specifications Table 22 Super DLTtape II Media Operating Limits Operating Conditions Temperature 10 ° to 40 °C (50 ° to 104 °F) Relative Humidity 20% to 80% (non-condensing) Table 23 describes the optimum media storage conditions.
Chapter 2 SDLT 600 Tape Drive Specifications Recording Media Specifications Backward-Read Compatibility Transfer Rates 2 The SDLT 600 tape drive system features a backward-read compatibility (BRC) mode. When in BRC mode, the SDLT 600 tape drive is capable of reading SDLT 220 and SDLT 320 tape formats in a Super DLTtape I data cartridge, as well as the DLT VS160 tape format in the DLTtape VS1 data cartridge. Table 24 lists the BRC transfer rates for the SDLT 600 tape drive.
Chapter 3 Installing Your Tape Drive 3 This chapter describes how to install the SDLT 600 tape drive. This includes configuration jumper settings, connector pin assignments, installation instructions, power and signal cabling descriptions, and operating instructions. This chapter also includes information on configuring and connecting the tabletop version of the tape drive into a system.
Chapter 3 Installing Your Tape Drive Warranty Note • Configuring and Installing a Tabletop Tape Drive with SCSI Interface describes how to configure and install the tabletop version of the tape drive. • Confirming the Installation describes how to confirm that the tape drive has been installed correctly. Warranty Note 3 Please refer to the warranty before installing your tape drive. Certain actions taken during installation could void the warranty if not properly conducted.
Chapter 3 Installing Your Tape Drive Safety, Handling, and ESD Protection Safety Precautions 3 For your safety, follow all safety procedures described here and in other sections of the manual. 1 Power off the system before installing or removing the tape drive to prevent the possibility of electrical shock or damage to the tape drive. Unplug the unit that contains—or is to contain—the tape drive from AC power to provide an added measure of safety. 2 Read, understand, and observe all label warnings.
Chapter 3 Installing Your Tape Drive Safety, Handling, and ESD Protection • Always handle the tape drive carefully and gently. A drop of ¼ inch onto a bench or desktop may damage a tape drive. • Never place the tape drive so that it rests on its front bezel. Always gently place the tape drive flat, printed circuit board (PCB) side down, on an appropriate ESD-protected work surface to avoid the tape drive being accidentally knocked over.
Chapter 3 Installing Your Tape Drive Pre-Installation Guidelines • Do not remove covers to use any test equipment to check components on the PCBAs. There are no user-serviceable components on the tape drive. Pre-Installation Guidelines 3 Before you begin, check the contents of the box and record the applicable numbers. Since the tape drive may be either SCSI or Fibre Channel interface type (never both), check for SCSI (or Fibre Channel) controller and associated cable compatibility.
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface 5 Confirm that your back-up software and operating system are compatible with the tape drive. See www.dlttape.com for the most up-to-date compatibility information. Configuring and Installing an Internal Tape Drive with SCSI 3 Interface This section provides information for configuring and installing a tape drive with SCSI interface into a system.
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface Figure 5 shows the empty 10-pin jumper block that you use to set the SCSI ID. Figure 6 shows the location of the 10-pin SCSI ID block on the back of the tape drive. If you decide it is necessary to change the tape drive’s SCSI ID, use your fingers to move the jumpers to the pattern corresponding to the ID you want (see figure 5 and the related table of SCSI jumper settings in table 25 and table 26).
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface Table 25 SCSI ID Address Selections (Graphical Format) SCSI ID 0 1 2 3 4 5 (default) 6 7 8 9 10 11 12 13 14 15 Jumper Block SCSI ID Jumper Block SCSI ID Jumper Block SCSI ID Jumper Block Note: SDLT 600 Product Manual The computer system and the tape drive SCSI IDs are only checked at power-on.
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface Figure 6 10-pin SCSI ID Jumper Block on Rear of Tape Drive SCSI ID Jumper Block (No jumpers on this block selects default SCSI ID of 5) Table 26 SCSI ID Address Selections (Tabular Format) SDLT 600 Product Manual SCSI ID Jumper Across Pins 9-10* 7-8 5-6 3-4 1-2 0 1 0 0 0 0 1 1 0 0 0 1 2 1 0 0 1 0 3 1 0 0 1 1 4 1 0 1 0 0 5 (default) 0 0 0 0 0 6 1 0 1 1
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface SCSI ID Jumper Across Pins 9 1 1 0 0 1 10 1 1 0 1 0 11 1 1 0 1 1 12 1 1 1 0 0 13 1 1 1 0 1 14 1 1 1 1 0 15 1 1 1 1 1 0 = No Jumper installed, 1 = Jumper installed * Configuring the Internal SCSI Tape Drive for 3 TERMPWR Jumpering Pins 9-10 forces the tape drive to ignore the firmware value and read the value jumpered on the block.
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface Figure 7 TERMPWR Jumper Block on Rear of Tape Drive TERMPWR Block (4 pin) Pin 1 (Install jumper on Pins 1-2 to enable TERMPWR) Pin 2 Installing the Internal SCSI Securing the Internal Tape Drive describes installing the tape drive by 3 securing the tape drive in its bay or chassis and connecting the SCSI bus Tape Drive (or Fibre Channel) and power cables.
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface Figure 8 Internal SCSI Tape Drive Front and Rear View Front View Rear View 3 Securing the Internal Tape Drive This section describes how to mount and secure the tape drive in the system. Note: In some system configurations, it may be more convenient to connect the SCSI bus and power cables to the tape drive before securing it in the system.
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface Figure 9 Internal Tape Drive Mounting Locations – Front, Side, and Bottom Dimensions 3 Connecting the Internal Tape Drive Cables This section discusses three connectors on the back of the internal SDLT 600 tape drive: 1) SCSI, 2) power, and 3) optional library/loader connectors. Figure 10 shows some typical AC power cord connectors used for the tabletop model.
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface and MSE Low Voltage Differential (LVD) mode in table 28 on page 53. Pin assignments for the power connector are listed in table 29 on page 55. 1 Before connecting the SDLT 600 tape drive to the host computer, be certain the tape drive and computer are powered off. 2 Ensure that your SCSI cables and terminators are SPI-3 (or SPI-4) compatible.
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface Figure 10 Connectors on the Rear Panel of Internal SCSI Tape Drive Power Connector (4 pin) Controller Diag Port (8 pin) (Diagnostic use only) SCSI Port (68 pin) Pin # 1 Loader Connector RS-422 (8 pin) SCSI ID Jumper Block (No jumpers on this block TERMPWR Block (4 pin) or Denotes Pin # 1 selects default SCSI ID of 5) SDLT 600 Product Manual 51
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface Table 27 MSE and SE Mode SCSI Connector Pin Assignments SDLT 600 Product Manual Signal Name Pin Number Pin Number Signal Name Ground 1 35 -DB(12) Ground 2 36 -DB(13) Ground 3 37 -DB(14) Ground 4 38 -DB(15) Ground 5 39 -DB(P1) Ground 6 40 -DB(0) Ground 7 41 -DB(1) Ground 8 42 -DB(2) Ground 9 43 -DB(3) Ground 10 44 -DB(4) Ground 11 45 -DB(5) Ground 12
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface Signal Name Pin Number Pin Number Signal Name Ground 25 59 -RST Ground 26 60 -MSG Ground 27 61 -SEL Ground 28 62 -C/D Ground 29 63 -REQ Ground 30 64 -I/O Ground 31 65 -DB(8) Ground 32 66 -DB(9) Ground 33 67 -DB(10) Ground 34 68 -DB(11) Note: Table 28 MSE LVD SCSI Connector Pin Assignments SDLT 600 Product Manual The minus sign (-) next to a signal indicat
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with SCSI Interface SDLT 600 Product Manual Signal Name Pin Number Pin Number Signal Name +DB(6) 12 46 -DB(6) +DB(7) 13 47 -DB(7) +DB(P) 14 48 -DB(P) Ground 15 49 Ground DIFFSENS 16 50 Ground TERMPWR 17 51 TERMPWR TERMPWR 18 52 TERMPWR Reserved 19 53 Reserved Ground 20 54 Ground +ATN 21 55 -ATN Ground 22 56 Ground +BSY 23 57 -BSY +ACK 24 58 -ACK +RST 25 59 -RST
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with Fibre Channel Interface Table 29 4-Pin Power Connector Pin Assignments Pin Number Signal Name 1 +12 VDC 2 Ground (+12V return) 3 Ground (+5V return) 4 +5 VDC Table 30 8-Pin Loader Connector Pin Assignments Signal Name Pin Number Pin Number Signal Name Ground 1 5 SEND_TO_LOADER_H REC_FROM_LOADER_H 2 6 SEND_TO_LOADER_L REC_FROM_LOADER_L 3 7 Ground Ground 4 8 LOADER_PRESENT_L Configuring
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with Fibre Channel Interface Fibre Channel is an open T11 and ANSI standard based on a blockoriented serial network protocol that brings together some of the best features of the channel world and the network world. Fibre Channel is full-duplex (meaning that data can travel in both directions simultaneously), and offers a variety of different cabling options.
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with Fibre Channel Interface Figure 11 Internal Fibre Channel Tape Drive Connectors and Jumpers Controller Diag Port (8 pin) Power Connector (Diagnostic use only) (4 pin) Loader Connector Fibre Channel Jumper Block RS-422 (8 pin) Fibre Channel Port or Denotes Pin # 1 Follow these steps to connect a Fibre Channel tape drive: 1 Secure the tape drive. 2 Connect the power. 3 Connect the library/loader (optional).
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with Fibre Channel Interface Secure the Tape Drive 3 This section describes how to mount and secure the tape drive in the system. Note: In some system configurations it may be more convenient to connect the Fibre Channel and power cables to the tape drive before securing it in the system. Because of the variety of mounting possibilities for tape drives, the instructions presented here are general in nature.
Chapter 3 Installing Your Tape Drive Configuring and Installing an Internal Tape Drive with Fibre Channel Interface Optional Loader Connector 3 The 8-pin optional loader connector provides signals to be used when the tape drive is part of a loader/library configuration. Figure 11 shows the location of this connector; table 30 on page 55 lists pin assignments for the loader connector.
Chapter 3 Installing Your Tape Drive Configuring and Installing a Tabletop Tape Drive with SCSI Interface Configuring and Installing a Tabletop Tape Drive with SCSI Interface 3 This section provides instructions for configuring and installing the tabletop SCSI model of the SDLT 600 tape drive. Configuring the SCSI Tape Figure 13 shows the location of the controls and connectors for the 3 tabletop tape drive.
Chapter 3 Installing Your Tape Drive Configuring and Installing a Tabletop Tape Drive with SCSI Interface 3 SCSI ID The SCSI ID default for the tabletop tape drive is set to 3; you can configure the tape drive for SCSI ID addresses that range from 0 to 15 using the SCSI ID pushbutton. Press the button above or below the ID number display to set the desired SCSI ID. The top button increases the ID number, the bottom button decreases the ID number.
Chapter 3 Installing Your Tape Drive Configuring and Installing a Tabletop Tape Drive with SCSI Interface Installing the SCSI Tabletop Tape Drive 3 Tabletop tape drive installation consists of connecting SCSI bus and power cables. Figure 13 shows the location of the two SCSI bus connectors and power connector on the back of the tabletop tape drive. 3 SCSI Cables You can connect the SCSI bus cable leading from the host adapter to either of the tape drive SCSI connectors.
Chapter 3 Installing Your Tape Drive Configuring and Installing a Tabletop Tape Drive with SCSI Interface 1 Prior to connecting the SDLT 600 tape drive to the host computer, be certain the tape drive and computer are turned off. 2 If you are connecting several devices to the SCSI bus, connect only the tape drive to the host computer at this time. Confirm that the host computer and tape drive are communicating correctly before adding additional devices. 3 You must terminate the SCSI bus at each end.
Chapter 3 Installing Your Tape Drive Configuring and Installing a Tabletop Tape Drive with SCSI Interface • UL and CSA certified cordage rated for use at 250 V AC with a current rating that is at least 125% of the current rating of the product. • You must terminate the AC plug in a grounding-type male plug designed for use in your country or region. It must also have marks showing certification by an agency acceptable in your country or region.
Chapter 3 Installing Your Tape Drive Configuring and Installing a Tabletop Tape Drive with SCSI Interface Configuring and Installing a Tabletop Tape Drive with SCSI Interface 3 This section provides instructions for configuring and installing the tabletop Fibre Channel model of the SDLT 600 tape drive.
Chapter 3 Installing Your Tape Drive Configuring and Installing a Tabletop Tape Drive with SCSI Interface Figure 17 Connecting the Fiber Optic Cable to a Tabletop Fibre Channel Tape Drive Fiber optic cable SDLT 600 tape drive 3 AC Power Cable An AC power cord is supplied with each tabletop unit. Carefully inspect the power cord and ensure that the cord is the appropriate cord for your country or region based on the criteria below.
Chapter 3 Installing Your Tape Drive Configuring and Installing a Tabletop Tape Drive with SCSI Interface • You must terminate the AC plug in a grounding-type male plug designed for use in your country or region. It must also have marks showing certification by an agency acceptable in your country or region. • The tabletop unit cord connector must be an IEC type CEE-22 female connector. • The cord must be no longer than 4.5 meters (14.5 feet). • The cord must be FCC compliant with emissions specifications.
Chapter 3 Installing Your Tape Drive Confirming the Installation Confirming the Installation 3 To confirm the installation, power on the SDLT 600 tape drive system and the host computer. The screens displayed at power-on contain BIOS, operating system, and SCSI controller information. If the first screen displays host adapter and SCSI ID information, then the installation is successful. See Troubleshooting on page 80 if the installation is not successful.
Chapter 4 4 Using Your Tape Drive This chapter describes how to start using your SDLT 600 tape drive system. This includes making a trial back-up, cleaning the tape mechanism, and various troubleshooting information. This chapter also includes information on the LEDs and buttons on the front panel of the system. This chapter covers the following topics: SDLT 600 Product Manual • Power-On Self-Test describes the sequence of activities that occur when power is first applied to the tape drive.
Chapter 4 Using Your Tape Drive Power-On Self-Test Power-On Self-Test 4 The SDLT 600 tape drive system performs a Power-On Self-Test (POST) each time the tape drive is powered on. POST normally completes in 10 to 15 seconds—when a data cartridge is not in the tape drive— when the unit is powered on. However, if a data cartridge is in the tape drive when the unit is powered on, POST duration is longer, depending on how much tape in the data cartridge may be loaded in the tape drive.
Chapter 4 Using Your Tape Drive Performing a Trial Back-up Stage Note: What You Observe If a data cartridge is in place when power is turned on, all stages remain the same except stage 3. It may take a considerably longer time for stage 3 to complete due to tape rewind and searching operations that occur during that stage.
Chapter 4 Using Your Tape Drive Updating the Firmware • If you experience errors, doublecheck the tape drive’s configuration and setup, using the ideas provided in Troubleshooting on page 80. • After you have exhausted all troubleshooting alternatives, contact your service representative. • Press the Eject button to unload the data cartridge. If you are unsure which button is the Eject button, see figure 20 on page 77.
Chapter 4 Using Your Tape Drive Updating the Firmware Refer to the following procedure to access and download these updates. 1 Go to the Quantum Web site: http://www.quantum.com. 2 Click SERVICE AND SUPPORT in the upper menu bar. This opens the Service and Support window. 3 Explore the various pages that comprise Service and Support until you find the update you need.
Chapter 4 Using Your Tape Drive Updating the Firmware 3 Press and hold the Eject button for six seconds; after six seconds, the left (Drive Density) LED begins to flash. 4 Release the Eject button, then quickly press and release the Eject button again. At this point, the left (Drive Density) and middle (Drive Status) LEDs start flashing synchronously in a regular, rhythmic pattern. The tape drive is now in Firmware Upgrade mode. You now have a “window” of one minute to insert the CUP/FUP data cartridge.
Chapter 4 Using Your Tape Drive Cleaning the Tape Mechanism Firmware (Code) Update 4 Troubleshooting Try these remedial actions if the tape drive’s code update fails: • Updating the same revision If you request a code update that is the same as the code revision already on the tape drive, the system updates the controller code but not the servo-specific code. The steps for this type of update are the same as for a normal update.
Chapter 4 Using Your Tape Drive Cleaning the Tape Mechanism Clean the SDLT 600 tape drive with the SDLT CleaningTape, which is also used to clean the SDLT 220 and SDLT 320 tape drives. Caution: When to Use the Cleaning 4 Tape Use ONLY the SDLT CleaningTape. Other cleaning tapes, such as CleaningTape III or DLT VS CleaningTape, are incompatible with the SDLT 600 tape drive heads. The SDLT 600 tape drive uses a built-in tape cleaning algorithm in conjunction with a cleaning tape.
Chapter 4 Using Your Tape Drive Front Panel Controls and LEDs 2 When the cleaning cycle completes, the cleaning tape automatically ejects from the tape drive and the yellow alert LED turns off. Note: On the last cleaning, the cleaning tape will not eject. Use the Eject button on the front of the tape drive to eject the expired cleaning tape and dispose of the cleaning tape. 3 Remove the cleaning tape, place it back into its plastic case, and mark the label after each cleaning.
Chapter 4 Using Your Tape Drive Front Panel Controls and LEDs On the SDLT 600 tape drive, the leftmost LED is dual color (green/ orange). This LED is the Density Indicator. When you insert a Super DLTtape II data cartridge, this LED illuminates green. When the tape drive detects a backward read compatible (BRC) data cartridge, this LED illuminates orange.
Chapter 4 Using Your Tape Drive Front Panel Controls and LEDs Table 33 How to Interpret the Front Panel LEDs and Other Controls LED/Button/ Port Title Color/ Symbol Drive Density LED Orange/ Green Action Explanation On/Off See table 32. The tape drive is in use. This includes functions such as: Flashing Green Drive Status LED Cleaning Required LED • The tape is moving. • The tape drive is calibrating, reading, writing, or rewinding the tape. • The tape drive is loading, unloading, or rewinding.
Chapter 4 Using Your Tape Drive Troubleshooting LED/Button/ Port Title Color/ Symbol Infrared Communication Port Note: Action Explanation This infrared port, also known as iTalk, provides a wireless remote testing base for customers and integrators to access system diagnostic information. See your Quantum sales representative for more information. Whenever the tape drive resets, all LEDs illuminate briefly and then illuminate in sequence until the reset completes.
Chapter 4 Using Your Tape Drive Troubleshooting Table 34 Troubleshooting Chart If… Then… You should… System does not recognize the SDLT 600 tape drive system. System may not be configured to recognize the interface ID. Configure system to recognize the SDLT 600 tape drive system’s ID. Interface ID may not be unique. Change the interface ID and reconfigure the system. The new ID becomes effective at the next power on or interface bus reset. Interface adapter parameters may not be correct.
Chapter 4 Using Your Tape Drive Troubleshooting If… Then… You should… System does not recognize the SDLT 600 tape drive system. (continued) Too many devices on the bus. Limit the number of devices on the bus (including the interface adapter) to match the limits of the interface being used. A device may not have been turned on and a valid interface ID may not have been configured before the system powering on and loading BIOS. Turn the tape drive power on first, and then turn on power to the system.
Chapter 5 Regulatory Compliance 5 This chapter describes various regulations that apply to the SDLT 600 tape drive: • Safety Regulations • Electromagnetic Field Specifications • Acoustic Noise Emissions • Class A Statements (Internal Tape Drive) • Class B Statements (Tabletop Tape Drive) • Environmental Compliance • Disposal of Electrical and Electronic Equipment Safety Regulations 5 This section lists the safety regulations that the SDLT 600 tape drive meets or exceeds.
Chapter 5 Regulatory Compliance Electromagnetic Field Specifications • UL 60950: Information Technology Including Electrical Business Equipment (USA) • EN60950/IEC 950: Information Technology Including Electrical Business Equipment (Europe) • EN60825-1 Information Technology Equipment The SDLT 600 tape drive is also certified to bear the GS mark. The SDLT 600 tape drive is a Class I laser product that complies with 21 CFR 1040.10 as applicable on the date of manufacture.
Chapter 5 Regulatory Compliance Electromagnetic Field Specifications Immunity and ESD Limits 5 Type Regulation/Certification CNS 13438 BSMI Class A (Taiwan) AS/NZS 3548 Australia/New Zealand Table 36 lists the immunity and ESD failure level limits to which the SDLT 600 tape drive has been tested.
Chapter 5 Regulatory Compliance Acoustic Noise Emissions Test Name AC Voltage Dips and Interrupts Immunity Test Specification Required Performance EN61000-4-11 Criteria B Acoustic Noise Emissions 5 Table 36 lists acoustic noise emission levels, both as noise power and sound pressure, for the SDLT 600 tape drive. The table provides the preliminary declared values per ISO 9296 and ISO 7779/EN27779.
Chapter 5 Regulatory Compliance Class A Statements (Internal Tape Drive) instruction manual, may cause harmful interference to radio communications. Any changes or modifications made to this equipment may void the user's authority to operate this equipment. Operation of this equipment in a residential area may cause interference in which case the user at his own expense will be required to take whatever measures may be required to correct the interference.
Chapter 5 Regulatory Compliance Class A Statements (Internal Tape Drive) welchen Fällen der Benutzer für entsprechende Gegenmaßnahmen verantwortlich ist. 5 Attention! Ceci est un produit de Classe A. Dans un environnement domestique, ce produit risque de créer des interférences radioélectriques, il appartiendra alors à l'utilisateur de prendre les mesures spécifiques appropriées. Taiwan (BSMI) Statement 5 !" #$%&'()*+ ,-.
Chapter 5 Regulatory Compliance Class B Statements (Tabletop Tape Drive) 5 DEN-AN Notice (Japan) Class B Statements (Tabletop Tape Drive) FCC Statement 5 5 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment.
Chapter 5 Regulatory Compliance Class B Statements (Tabletop Tape Drive) Operation of this equipment in a residential area may cause interference in which case the user at his own expense will be required to take whatever measures may be required to correct the interference.
Chapter 5 Regulatory Compliance Environmental Compliance Environmental Compliance 5 Quantum is committed to providing quality products in an environmentally sound manner and to comply with all applicable environmental laws, rules and regulations. This product was designed, manufactured and made available with consideration to worldwide laws, rules and regulations applicable to the product and the electronics industry including the European Union Directives 2002/95/EC & 2002/96/EC (RoHS and WEEE).
Appendix A 1 Super DLTtape I and Super DLTtape II Data Cartridges This appendix discusses Super DLTtape I and Super DLTtape II data cartridge information. Information in this appendix includes the following topics: • Recognizing Quantum Super DLTtape I and II Data Cartridges • Data Cartridge Handling Guidelines • Data Cartridge Inspection Procedure • Data Cartridge Write-protect Switch • Loading a Data Cartridge • Unloading a Data Cartridge. Appendix B for DLTtape VS1 data cartridge information.
Recognizing Quantum Super DLTtape I and II Data Cartridges Recognizing Quantum Super DLTtape I and II Data Cartridges 1 The Super DLTtape I data cartridge is dark green. The Super DLTtape II data cartridge is dark blue. Both data cartridges have a keying feature that prevent insertion into the older generation DLT tape drives. Note: You cannot insert the Super DLTtape II data cartridge into an SDLT 220 or SDLT 320 tape drive; or any other earlier model Quantum tape drive.
Data Cartridge Handling Guidelines Note: The Super DLTtape I and Super DLTtape II data cartridges have a keying feature to ensure you cannot load them into a previous generation DLT tape drives.
Data Cartridge Handling Guidelines Note: If storage or transportation of a data cartridge has exposed it to conditions outside the ambient values shown above, you should condition the data cartridge to its operating environment for a 24-hour period. • Maintain clean and smoke-free operating and storage environments. • Never expose the data cartridge to moisture or direct sunlight.
Data Cartridge Inspection Procedure Data Cartridge Inspection Procedure 1 Ensure your data cartridge backup solution performs reliably by following the Visual Mechanical Inspection (VMI) procedures described in this subsection. These steps will help you identify any potential data cartridge problems, and will prevent accidental loss of data or damage to your SDLT 600 tape drive system.
Data Cartridge Inspection Procedure Figure 22 Bottom View of Super DLTtape II Data Cartridge Spring-loaded Hub Reel Lock 5 See figure 23 and check the reel lock openings to ensure the small plastic tabs inside are partially visible. The reel locks are black. The reel locks can break if you drop the data cartridge. If the reel lock tabs are not visible, do not use the data cartridge.
Data Cartridge Inspection Procedure Figure 23 Super DLTtape II Data Cartridge Reel Locks Reel Lock Reel Lock 6 Once again, look at the end of the data cartridge, holding it as shown in figure 24.
Data Cartridge Write-protect Switch 7 Open the data cartridge door by pressing on the tab in the door pivot notch as shown in figure 24. Use care that you do not touch the tape leader. 8 Compare what you see inside the data cartridge door to figure 25. Look for damage to the data cartridge clips, including: • Bent or towed-in appearance on one or both clips • Improper seating (clips should be fully retracted towards the left side of the opening) • Bending of the leader bar that supports the clips.
Data Cartridge Write-protect Switch drive, position the write-protect switch on the front of the data cartridge (figure 26) according to the type of operations you expect to perform.
Data Cartridge Write-protect Switch Table 37 Write-Protect Switch Positions Orange Write-protect Indicator Write-protect Switch Position Result Before Loading the Data Cartridge Enabled (Slide switch to left) Visible You cannot write data to the media. You cannot overwrite existing data on the media. You cannot append additional data to the media. Disabled (Slide switch to right) Not Visible Unless the data cartridge is write-protected via firmware: - You can write data to the media.
Loading a Data Cartridge Loading a Data Cartridge 1 Complete this subsection to load a data cartridge into the front of the tape drive; see figure 27 as needed. 1 Insert the data cartridge into the front of the tape drive, as shown in figure 27. 2 Push the data cartridge fully into the tape drive. The Drive Status LED flashes to show that the media is loading. When the media reaches the Beginning of Tape (BOT) marker, the LED lights steadily. The data cartridge is now ready for use.
Unloading a Data Cartridge Unloading a Data Cartridge 1 Follow these steps to unload a data cartridge; see figure 27 as needed. Caution: Remove the data cartridge from the tape drive BEFORE turning off host power. Failure to remove a data cartridge may result in data cartridge or tape drive damage. Do NOT rush removal of the data cartridge. Wait until the tape drive ejects the data cartridge and the Drive Status LED lights steady before removing the data cartridge.
Appendix B DLTtape VS1 Data Cartridge 2 The SDLT 600 tape drive is backward read compatible with DLTtape VS1 data cartridges formatted in the DLT VS 160 tape drive. Data backed up using a DLTtape VS1 data cartridge in a DLT VS160 tape drive is retrievable using the SDLT 600 tape drive.
Data Cartridge Handling Guidelines Data Cartridge Handling Guidelines 2 Ensure your data cartridge backup solution performs reliably by following these general handling guidelines: • Always keep each data cartridge in its protective plastic case when it is not in the tape drive. • When carrying data cartridges in their cases, always orient the cases so that the grooves in the cases interlock. This prevents the cases from slipping apart and falling.
Data Cartridge Inspection Procedure • Do not touch or allow direct contact with media or tape leader. Dust or natural skin oils can contaminate the data cartridge and impact media performance. • Do not insert any data cartridge that has been dropped into the SDLT 600 tape drive without at least a thorough visual inspection, as described in Data Cartridge Inspection Procedure on page 106. A dropped data cartridge may have dislodged, loosened, or damaged internal components.
Data Cartridge Inspection Procedure • If a data cartridge is dropped or subjected to some hard physical shock. • If the SDLT 600 tape drive becomes inoperable after loading a data cartridge. • If you receive a shipment of data cartridges that show any sign of shipping damage. Follow these steps to visually inspect a DLTtape VS1 data cartridge: 1 Remove the data cartridge from its protective plastic case. 2 Gently shake the data cartridge.
Data Cartridge Inspection Procedure 5 See figure 29 and check the reel lock openings to ensure the small plastic tabs inside are partially visible. The reel locks are black. The reel locks can break if you drop the data cartridge. If the reel lock tabs are not visible, do not use the data cartridge. Figure 29 DLTtape VS1 Data Cartridge Reel Locks Reel Lock Reel Lock 6 Look closely at the spring-loaded reel hub on the bottom of the data cartridge.
Data Cartridge Inspection Procedure Figure 30 Faulty Data Cartridge Spring-loaded Reel Hub Data cartridge hub is recessed slightly, and when pressed, does not return to a position that is flush with the plastic shell 7 Once again, look at the end of the data cartridge, holding it as shown in figure 31.
Data Cartridge Inspection Procedure Figure 32 End View of DLTtape VS1 Data Cartridge (Tape Leader Loop in its Correct Position) Data Cartridge Tape Leader Loop Media 10 Inside the door, you will see the media and tape leader loop. The loop should stick up about an eighth of an inch when viewed from the edge; the loop must be a closed loop. 11 Examine the visible tape leader to ensure it is in the correct position as shown in figure 32.
Data Cartridge Inspection Procedure Figure 33 DLTtape VS1 Data Cartridges with Visible Damage Broken tape leader loop Swallowed tape leader loop Loose media inside the data cartridge 13 Finally, check for proper operation of the data cartridge’s writeprotect switch (see figure 35).
Data Cartridge Write-Protect Switch Data Cartridge Write-Protect Switch 2 Each data cartridge has a write-protect switch that you can use to prevent accidental erasure of data. Before inserting the data cartridge into the tape drive, position the write-protect switch on the front of the data cartridge (figure 34) according to the type of operations you expect to perform.
Loading a Data Cartridge you move the write-protect switch to the left, a small closed padlock is visible. This is your visual reminder that you cannot write data to the media. • Slide the write-protect switch to the right to disable write protection (you can write over existing data on the media, and you can append additional data to the media unless the data cartridge is writeprotected via firmware). When write-protection is disabled, a small open padlock is visible.
Unloading a Data Cartridge Figure 35 Loading a DLTtape VS1 Data Cartridge Tape Drive Data Cartridge Eject Button Drive Status LED Unloading a Data Cartridge 2 Complete this subsection to unload a data cartridge; see figure 35 as needed. Caution: Remove the data cartridge from the tape drive BEFORE turning off host power. Failure to remove a data cartridge may result in data cartridge or tape drive damage. Do NOT rush removal of the data cartridge: premature removal can cause tape leader failure.
Glossary The following is an alphabetical list of specialized words and technical terms with their definitions, commonly used in the tape drive and tape media industry. A Access (v.) To read, write, or update information on a storage medium, such as magnetic media. (n.) The operation of reading, writing, or updating stored information. Access Time The interval between the time a request for data is made by the system and the time the data is available from the tape drive.
Glossary B Backup A copy of a file, directory, or volume on a separate storage device from the original, for the purpose of retrieval in case the original is accidentally erased, damaged, or destroyed. Bad Data Block A block that cannot reliably hold data because of a media flaw or damaged format markings. Base Plate An aluminum die casting that acts as the support platform for the other modules and for the tape drive enclosure.
Glossary Cartridge Receiver At media insertion, the cartridge receiver assembly is responsible for guiding the media into its operating position, opening the door, unlocking the cartridge brakes, and securing the media for operation. At media ejection, the cartridge receiver assembly reverses the process and automatically ejects the cartridge a fixed distance from the front of the tape drive. CE Council of Europe.
Glossary Differential A term referring to the electrical characteristics of the signal used on the SCSI bus interface. Differential signals minimize the effect of common mode signal noise and allow the SCSI bus to operate reliably over greater distances at a higher speed. DLT Digital Linear Tape. DLTIce Quantum’s firmware compliance management function of DLTSage, which provides secure archival functionality to the tape drive and tape cartridges.
Glossary Error A message that occurs when there is a loss of ability to interpret recorded data; usually because of magnetic issues or defects in or on the media. ESD An Electrostatic Discharge is a sudden flow of electric current through a material that is normally an insulator. EU European Union. F F Fahrenheit is a temperature scale where a degree Fahrenheit (°F) is 5/ 9ths of a kelvin (or of a degree Celsius). FCC Federal Communications Commission (United States).
Glossary H Head The tiny electromagnetic coil and metal pole used to create and read back the magnetic patterns on the media. Also known as the read/ write head. HiFN An ASIC (Application Specific Integrated Circuit) for the SDLT that handles data compression. HIM The Host Interface Module implements the interface between the host system and the tape drive. HRE Hard Read Error. HWE Hard Write Error.
Glossary LVD Low Voltage Differential signalling is an electrical signalling system that can run at high speeds over cheap, twisted-pair copper cables. M µM A Micrometer is an SI unit of length. It is defined as one millionth of a metre (1 × 10-6 m), equivalent to one thousandth of a millimeter. MAM Medium Auxiliary Memory (MAM) is an SDLT 600 tape drive feature that provides information on the status and prior use history of an DLTtape cartridge. MB Megabyte SI — 1 000 000 bytes or 106 bytes.
Glossary Positive Engagement Buckling Mechanism A highly robust, solidly engineered media leader-buckling mechanism for heavy-duty-cycle automated environments. POST Power-on Self-Test. When power is applied to the tape drive, it performs a POST. PRML Partial Response Maximum Likelihood is a method for converting the weak analog signal from the head of a magnetic disk drive into a digital signal. Also see Advanced PRML. PWA Printed Wiring Assembly.
Glossary SRAM Static RAM. A memory chip that requires power to hold its content. T Take-up Reel The reel inside every tape drive onto which DLTtape or Super DLTtape media is wound. The in-the-tape drive take-up reel enables DLTtape and Super DLTtape systems to operate using a singlereel cartridge and thereby pack more media and data into every cartridge. TapeAlert™ A firmware feature that monitors and returns the results of the tape drive’s on-going self-diagnosis activity.
Glossary V V A Volt is the potential difference across a conductor when a current of one ampere dissipates one watt of power. VCCI Voluntary Control Council for Interference by Information Technology Equipment (Japan). W W The Watt is the SI derived unit of power.
