Installing/Removing a RMU

Scalar 24

Installing/Removing a RMU

The Remote Management Unit (RMU) allows you to access your Scalar 24 library via a web

browser. Follow the procedures below to install or remove the RMU. For instructions on operating

the RMU, refer to the Scalar 24 Installation and Operation Guide.

The following is a list of items that should be included in your RMU kit.

When installed, the library will detect the presence of the RMU. However, you will need to set the

IP Address, Subnet Mask, and Gateway Address before the RMU will function. After you have

installed the RMU, see the instructions provided in Configuring the RMU

on page 3 for information

on configuring it.

Step 1 Remove the RMU from the packaging.

Step 2 Power down your Scalar 24 and disconnect the AC line cord from the AC source

outlet.

What’s in the Box?

Description Quantity

RMU 1

Installing a Remote Management Unit

Summary of content (6 pages)

PAGE 1
Scalar 24 Installing/Removing a RMU The Remote Management Unit (RMU) allows you to access your Scalar 24 library via a web browser. Follow the procedures below to install or remove the RMU. For instructions on operating the RMU, refer to the Scalar 24 Installation and Operation Guide. What’s in the Box? The following is a list of items that should be included in your RMU kit.
PAGE 2
Scalar 24 Step 3 From the rear of the Scalar 24, locate the available RMU slot. Loosen the thumbscrew on the cover plate and remove the cover plate. Store the cover plate in a convenient place. It is required for proper operation and cooling of the library if the RMU is ever removed. Step 4 Slide the RMU into position and tighten the thumbscrew. Step 5 Plug the power cord into a grounded electrical socket. Step 6 Connect the network cable to the RMU. Step 7 Power on the Scalar 24.
PAGE 3
Scalar 24 Removing a Remote Management Unit Follow these steps to remove a Remote Management Unit. Step 1 Power down the library and host. Step 2 On the rear of the library, disconnect the AC line cord and SCSI cables from the library. Step 3 Disconnect the network cable from the RMU. Step 4 Remove the RMU by loosening the thumbscrew and pulling out the RMU. Step 5 If you are not replacing this RMU, reinstall the cover plate you removed when you initially installed the RMU.
PAGE 4
Scalar 24 Setting the IP Address You must set the IP Address in the Scalar 24 before you can start the RMU. Follow the procedure below to configure your RMU. Alternatively, you can also configure the RMU through the Setup Wizard. NOTE: For more information, refer to the Scalar 24 Installation and Operation Guide. Path: Main Menu Setup Menu User Interface Selection Description/Result Configures the RMU. An error will appear if an RMU is not installed or is not functioning properly.
PAGE 5
Scalar 24 Selection Description/Result The current field will be highlighted. Make sure you enter a valid number for each field. Step 3 Set the Subnet mask by pressing and to change the value of the current field and and to move between fields. The current field will be highlighted. Make sure you enter a valid number for each field. Step 4 Set the Gateway by pressing and to change the value of the current field and and to move between fields.
PAGE 6
Scalar 24 Step 2 Point your browser to the RMU IP address, excluding any leading zeros. For example if your IP address is 182.073.056.052 on the Operator Panel LCD, go to the following address: http://182.73.56.52 The RMU displays.
