Chapter 2 Basic Operations
DX-Series Controller Operations
Quantum DX-Series User’s Guide 19
Figure 10 Power
Switch Locations
Controller
Power
Storage arrayPower
AC power sequencer
Power
(DX100 only)
DX-Series Controller Operations 2
The DX-Series controller contains the Linux operating system as well as
the Fibre Channel HBAs connecting the unit to the storage arrays and to
the customer host systems.
The front panel of the controller has a series of buttons and LED
indicators (see figure 11
).
