Quick Setup Guide

Management Mode
Quantum Networks’ Access Point can be configured in two modes:
Standalone
Independent management of each Access Point
Cloud Controlled
Centralized management of Access Points using Quantum RUDDER
Step 4 - Access Point Quick Setup in Standalone Mode
 Select “Management Mode” as “Standalone”, if each Access Point is to be
configured and managed individually. Define username and password for the device
and click “Next”.
 User can select Access Point Operation Mode as Bridge or Router.
Bridge
i. Select option Bridge and click Next.
ii. Configure WLAN (SSID) parameters and click Next.
Figure 5
Parameter
Value
Country
Select country
Timezone
Select timezone
WLAN Name
Define name for the network
SSID
Define visible wireless network name
Passphrase
Configure passphrase for SSID
