User's Manual
Table Of Contents
- Quanta_WCM_UserGuide_Ver 1 01_20070802.pdf
- 1. Introduction
- 2. Hardware installation
- 3. Driver installation and un-installation
- 3.1. Un-install the previous WiMAX NDIS Driver
- 3.2. Install WiMAX NDIS Driver
- 4. WiMAX Utility installation
- 4.1. .NET Framwork 2.0
- 4.2. WinPcap Library installation
- 4.3. Quanta WiMAX Connection Manager installation
- 5. Configure the WiMAX Card by Quanta WiMAX Connection Manager
- 5.1. Use Quanta WiMAX Connection Manager to setup WiMAX connection without security configuration
- 5.2. Use Quanta WiMAX Connection Manager to setup WiMAX connection with security configuration
- 6. Appendix
- 6.1. Use Quanta Config File Editor to setup configuration file parameters
- 6.2. Configuration File Parameters
- 6.3. Setup WCM network configuration to static IP address
- WC510_FCC_CE_Statement.pdf
Quanta Computer Inc.
http://www.quantatw.com/
1. Introduction
The CardBus of WiMAX Connection Manager supports IEEE 802.16e-2005 state of the art Scalable
OFDMA based Technology. It provides users a seamless broadband wireless access, video streaming at home,
office or on the move. To protect information transmitting through wireless network, standard security Sublayer
PKMv2 EAP based user authorization/authentication and AES for data encryption are supported.
Easy-to-use Windows XP-based utility provide the graphic user interface is for system/link status,
configuration and firmware upgrade.
The following chapters we will show you how to install from hardware to software step by step
Hardware Installation
NDIS Driver Installation and Old driver un-installation (for previous version)
Windows Utility Installation
.Net Framework 2.0
WinPcap Library
Quanta Wimax Connection Manager
2. Hardware installation
1. Locate the available CardBus card slot on your
Laptop.
2. Then insert the CardBus Subscriber into the
CardBus card slot.
3. Remove method: To remove the CardBus
Subscriber, Please press the Eject Button of the
CardBus card slot. To make it stretch out. Then,
push the Eject Button and the CardBus
Subscriber will slide out slightly. And pull it out
of the slot.
Page 4
