NumOfSAId
RadioParameter [3:0] = 2, always
[7:4] is Band Select
[15:8] is a board type that should be zero
unless specified by Beceem otherwise.
For example:
0x22: For MS120 units supporting Board
Type 2.3 to 2.4G
0x32: For MS120 units supporting Board
Type 2.5 to 2.7G
0x42: For MS120 units supporting Board
Type 3.4 to 3.6G
For BCS200, Band Select is a don’t care.
Radio Parameter is obvious
when Center Frequency is
non-zero and is a don’t care
in such a case
PhyParameter1 This parameter decides the number of DL, UL
symbols
and TTG value.
0xFFFFFFFF: This is a special value. It
forces Use of
values as defined in firmware for a given
Bandwidth selection.
Other values can be configured as follows
PhyParameter1 e.g. 0xccccbbaa
cccc = [31:16] 80 * Value of TTG in us
bb = [15:08] Number of DL symbols
aa = [07:00] Number of UL symbols
Example:
for 26 DL, 21 UL, TTG =
105.71us, program as
0x21091a15
PhyParameter2
PhyParameter3
m_u32TestOptions
MaxMACDataperDLFrame
MaxMACDataperULFrame
Corr2MacFlags This parameter consists of a bit map for
enabling/disabling Corrigendum-2 updates.
This should
be 0 unless testing for Corrigendum-2.
Bit 0: ARQ
Bit 1: Encryption
Bit 2: HARQ
Bit 3: HO
Bit 4: Idle Mode
Bit 5: Sleep Mode
Bit 6: MBS
Bit 7: MIB
Bit 8: MIMO
Bit 9:
Bit 10: Network Entry
Bit 11:
Bit 12: RLC – NE
Bit 13: Security
Bit 14 Signaling/DSx
Bit 15: RLC-Other
