Owner manual

Labels
!
WARNING
1-800-466-6385
6305 S. 231st St.
Kent, WA 98032
www.guardianfall.com
Permanent Adjustable Standing Seam Roof Anchor
Part #: 00249 Date of manufacture:
Compliant with all OSHA 1910, 1926 Subpart M,
ANSI Z359.1-2007, and ANSI A10.32-2012 regulations.
Prior to use, read and understand all manufacturer’s
instructions provided with equipment at
time of shipment from manufacturer.
Worker capacity: 130-310 lbs. (including all equipment)
unless used with system components certified for up to 420 lbs.
Material: Aluminum and stainless steel.
All connections must be selected and deemed compatible
with the Permanent Adjustable Standing Seam
Roof Anchor by a Competent Person.
S-5 Set Screw torque requirements:
13.33-15 foot-pounds on 22 gauge steel or thicker,
10.83-12.5 foot-pounds on steel thinner than 22 gauge.
Ensure roof seam compatibility prior to installation.
Prior to use, ensure all Set Screws are torqued correctly.
Refer to instructions for installation requirements.
DO NOT REMOVE LABELS
If equipment fails inspection
IMMEDIATELY REMOVE FROM SERVICE
User must inspect prior to EACH use. Competent Person must complete formal inspection every 6 months. Competent Person to inspect and initial.
INSPECTION GRID
Date of First Use: __________________. Product lifetime is indefinite as long as equipment passes pre-use and Competent Person inspections.
YR J F M A M J J A S O N D
20____ 20____ 20____ 20____ 20____
90027 (Rev. C)
DO NOT REMOVE LABEL
If equipment fails inspection
IMMEDIATELY REMOVE FROM SERVICE
User must inspect prior to EACH use. Competent Person must complete
formal inspection every 6 months. Competent Person to inspect and initial.
INSPECTION GRID
Date of First Use: __________________. Product lifetime is indefinite as
long as equipment passes pre-use and Competent Person inspections.
YR J F M A M J J A S O N D
20____
20____
20____
20____
20____
Label locations
!
WARNING
1-800-466-6385
6305 S. 231st St.
Kent, WA 98032
www.guardianfall.com
Permanent Adjustable Standing Seam Roof Anchor
Part #: 00249
Date of manufacture:
Compliant with all OSHA 1910, 1926 Subpart M,
ANSI Z359.1-2007, and ANSI A10.32-2012 regulations.
Prior to use, read and understand all manufacturer’s
instructions provided with equipment at
time of shipment from manufacturer.
Worker capacity: 130-310 lbs. (including all equipment)
unless used with system components certified for up to 420 lbs.
Material: Aluminum, stainless steel, steel.
All connections must be selected and deemed compatible
with the Permanent Adjustable Standing Seam
Roof Anchor by a Competent Person.
S-5 Set Screw torque requirements:
160-180 inch-pounds on 22 gauge steel or thicker,
130-150 inch-pounds on steel thinner than 22 gauge.
Ensure roof seam compatibility prior to installation.
Prior to use, ensure all Set Screws are torqued correctly.
Refer to instructions for installation requirements.
90027 (Rev. B)
