NMEA has the following application layer protocol rules:
• Each message's starting character is a dollar sign. 
• The next five characters identify the talker (two characters) and the type of message
(three characters).
• All data fields that follow are comma-delimited.
• Where data are unavailable, the corresponding field contains NULL bytes (e.g., in
"123,,456", the second field's data are unavailable).
• The first character that immediately follows the last data field character is an asterisk.
• The asterisk is immediately followed by a two-digit checksum representing a hex number.
The checksum is the exclusive OR of all characters between the $ and the *. According
to the official specification, the checksum is optional for most data sentences, but is
compulsory for RMA, RMB, and RMC (among others).
• <CR><LF> ends the message.
As an example, a waypoint arrival alarm has the form:
$GPAAM,A,A,0.10,N,WPTNME*32 
where:
Table 12-2: NMEA data format
GP

Talker ID (GP for a GPS unit

AAM

Arrival alarm

A

Arrival circle entered

A

Perpendicular passed

0.10

Circle radius

N

Nautical miles

WPTNME

Waypoint name

*32

Checksum data

14.16 NO_EVENT
Occurs periodically (once per second by default). An application can use this event to perform
periodic status updates.
14.17 ORB_ANTENNA_VSWR
An ORBCOMM Antenna VSWR measurement result is available in 0.1 units (e.g. 15 => 1.5:1
VSWR).
14.18 POSITION_ALARM
A GPS measurement completed and a Geo-Fence violation occurred. The parameter indicates
which Sensor Table was used. This function is currently unsupported. Please contact QUAKE
Global if you would like to implement GEO_fencing in your product.
