The message packet should not be freed by the application; this is done by the
foundation code.
14.9 MTS_DTR
The DTR Line on the MTS Serial Port has changed state. If the parameter [0-1] is zero, it
indicates that the line has changed from High to Low Voltage; if one, it indicates the line has
changed from a Low to a High voltage.
14.10 MSG_MID_CHANGED
The message is queued to a secondary network.
14.11 MSG_NAK
The message was not sent by the primary network.
14.12 MSG_RCVD
A terrestrial or satellite message packet was received from one of three sources, determined by
parameter 1:
• TERR_SMS: an SMS message was received
• TERR_POP: a POP email message was received
• SATELLITE: a satellite message was received
The message length and data are contained in the incoming message.
14.13 MSG_SEND_NAK
The message was not sent and there will be no other attempts.
14.14 NET_CLEAR
The network is cleared.
14.15 NMEA_SENTENCE
The NMEA 0183 standard uses a simple ASCII, serial communications protocol that defines how
data are transmitted. The data are passed in to the application as a message parameter, along
with the length of the string as the parameter msgLen. The string is null terminated and can be
displayed in a printf() statement.
Note:
