A request for a CAN message with a specified Parameter Group Number (PGN) has been
processed. A parameter [0-65535] value indicates the PGN of the message received. A second
parameter value of 0 indicates the requested message was received; non-zero indicates an error,
typically a timeout.
14.1 CELL_NET_IN_VIEW
The cell network availability status has changed. Parameter value indicates:
0 – network is not available
1 – modem is registered on the GSM/GPRS network
2 - modem is connected to the GSM/GPRS network
14.2 CONTINUE
Used in Application Event Tables to indicate an additional Response Action for an event entry.
14.3 COUNTER
A software counter has reached 0, underflowed, or overflowed. The parameter indicates the
counter number.
14.4 DIGITAL
A Digital measurement has completed, and the measured value is within limits specified by the
Alarm High and Low values. The parameter [0-15] indicates which Sensor Table was used in
making the measurement.
14.5 DIGITAL_ALARM
A Digital measurement has completed, and the measured value violated limits specified by an
Alarm High or Low value. The parameter [0-15] indicates which Sensor Table was used in
making the measurement.
14.6 GLSS_AVAILABLE
The Globalstar Simplex module availability status has changed: 0 means it is not ready for use; 1
indicates the module is working and ready to accept messages.
14.7 MSG_ACK
Receipt of a MSG_ACK event indicates that a message sent from the Q4000/QPRO was
successfully delivered. The parameter [0-255] indicates the message reference number (or other
tracking number if not an ORBCOMM message). This is currently supported for ORBCOMM and
GSM/GPRS networks. Message reception is managed by @ref MSG_RCVD.
14.8 MSG_ALERT
A message is available from the network.
