14 Event driven architecture
Event driven architecture is a significant element in the Q4000/QPRO user applications. Events
have been defined which correspond to significant internal and external signals and conditions
that are likely to appear. These events are then forwarded to the application.
Most actions the application takes in response to these events are handled by function calls.
Many of the calls represent high-level actions, such as “send this message,” which abstract the
low-level details. The Application Programming Interface (API) is set up so that these events are
mapped to the application developer's ‘C’ code. The following sections describe the supported
events and the circumstances under which they are posted.
The supported events of the Q4000/QPRO are:
• CAN_MSG
• CELL_NET_IN_VIEW
• CONTINUE
• COUNTER
• DIGITAL
• DIGITAL_ALARM
• GLSS_AVAILABLE
• MTS_DTR
• MSG_ACK
• MSG_ALERT,
• MSG_MID_CHANGED
• MSG_NAK
• MSG_RCVD
• MSG_SEND_NAK
• NET_CLEAR
• NMEA_SENTENCE
• NO_EVENT
• ORB_ANTENNA_VSWR
• POSITION_FIX
• POSITION_ALARM
• POWER_ON
• RX_MTS_PKT
• RX_SER_PKT
• SAT_IN_VIEW
• SHUTDOWN
• SPEED ALARM
• TIMER
• TIME_SYNC
• USER_CMD
