User`s guide

C – Messages
Port Loopback Test Dialog
59022-05 A C-15

C.9
Port Loopback Test Dialog
Table C-9. Port Loopback Test Dialog Messages
Message User Action
Attempt to put port in diagnostic state has
failed. Unable to continue with port test.
Verify that the user has permissions to
modify the configuration on the switch, that
the switch is reachable in the fabric, and
that the fabric is reachable from the user’s
workstation, then retry the configuration
change.
External port test requires a loopback
device be plugged into the selected port.
Click "OK" when loopback device is
installed.
Verify that a loopback device is attached to
the port before starting loopback test.
Failed to correctly restore port states for
one or more ports.
Return to the faceplate view and select
View>Port State to determine which port
was not restored to its original state.
Select the port, and then select Port>Port
Properties to restore the port state.
Invalid frame count value.
Or
Invalid frame size. Must be 36 to 2148.
Or
Invalid hex pattern. Up to 8 hex digits
allowed.
Verify that all information is valid and retry
the loopback test.
No device detected in selected port yet.
Test will not be run on empty port.
Verify that a loopback device is attached to
the port before starting loopback test.
Verify that the port is online with an active
login before starting the loopback test.
Request to get admin privileges failed. Verify that another user is not currently
modifying the switch configuration, using
either the management application, or a
telnet login, or any application, and then
retry the operation.
Request to start loopback test failed.
Or
Request to stop loopback test failed.
Or
Request for loopback test results failed
Or
Request to reset loopback test results
failed.
Verify that the user has permissions to
modify the configuration on the switch, that
the switch is reachable in the fabric, and
that the fabric is reachable from the user’s
workstation, then retry the configuration
change.
