Users Manual

5
3. Absolute Maximum Ratings
Parameter
With respect to
Rating
Unit
Supply voltage range
(VDD)
GND
-0.3 ~ 3.6
V
Digital IO pins range
GND
-0.3 ~ VDD+0.3
V
Voltage on the analog pins
range
GND
-0.3 ~ 2.1
V
Input RF level
5
dBm
Storage Temperature
range
-55 ~ 125
C
ESD Rating
HBM
± 2K
V
MM
± 100
V
*Stresses above those listed under “Absolute Maximum Rating” may cause permanent damage to the device. These are
stress ratings only; functional operation of the device at these or any other conditions above those indicated in the
operational
sections of this specification is not implied. Exposure to absolute-maximum-rated conditions for extended periods may
affect
device reliability.
*Device is ESD sensitive. Use appropriate ESD precautions. HBM (Human Body Mode) is tested under MIL-STD-883F
Method 3015.7. MM (Machine Mode) is tested under JEDEC EIA/JESD22-A115-A.
*Device is Moisture Sensitivity Level III (MSL 3)
