User's Guide

Pico Neo 3 VR Headset Details
VR Headset Status Indicator Legend
Blue: Powered on with battery over 20%
Yellow: Charging Battery is less than 98%
Red: Charging Battery is less than 20%
Red flashing Battery is less than 20%
Blue flashing: Shutting down
Green: Charging complete
Main Mic
Left Speaker
Right Speaker
Proximity Sensor
39
40
Top Power Cable
Do not fold,punch or pull
Tracking Cameras
Do not block during use
Air Vent
Battery Case
Back
Head-pad
Face Cushion
Removable
Top Strap
Removable
Side Strap
APP/BACK Button
CONFIRM Button
2nd Mic
Status
Indicator
POWER Button
Power on: Long press
Power off: Long press
for two seconds
for five seconds
•
•
Hardware Reset: Long
press for ten seconds
•
Short press to enter
sleep or wake up
* This interface is not a
standard USB-C Display
Port, it needs customized
PC VR DP Cable to connect
with PC.
•
USB-C Interface
LENS
Inter-pupillary
Distance Adjustment
Audio Jack
VOLUME
Button
The system wakes up when VR Headset is put on,
and
（Note： The function is supported
in Pico Neo 3 Pro only. Pico Neo 3 Pro
Eye is not supported.)
HOME Button
Return home screen:
Short press
Screen re-centering:
Long press
for secondone
Wake up:
Strap Dial
DP Cable
screw hole
Display Port Interface
to
Short press
Can be rotated up to
90 for user wearing
glasses
。
