Quick Installation Guide 8 Channel H.
Q-SEE QUICK INSTALLATION GUIDE MODEL NUMBER QR208-811 PART 1 - PACKAGE CONTENTS: QSDR008RTC DVR Power Supply For DVR Software CD 8 Cameras (4) QSM1424C (6mm Lens) (4) QSM1424W (3.6mm Lens) Power Supply & 8 -Way Splitter For Cameras Ethernet Cable 1|Page Pre-Installed Hard Drive Camera Cables (8 Included) USB 2.
Q-SEE QUICK INSTALLATION GUIDE MODEL NUMBER QR208-811 PART 2 - DVR CAMERA AND POWER CONNECTIONS (Figure 1) 1. Connect one end of the 60 Ft. extension cables to the cables that are connected to the cameras. 2. Connect the other end of the 60 Ft. extension cable to the DVR as illustrated in Figure 1. 3. Following the illustration in Figure 1, plug the power connecter of the 60 Ft. extension cable to the 8 way splitter. Repeat steps 1 through 3 for each camera. 4.
Q-SEE QUICK INSTALLATION GUIDE MODEL NUMBER QR208-811 PART 3 - CONNECTING THE DVR TO YOUR TV 1. Plug the BNC to RCA adapter in to Video Out port then connect the RCA cable (not included) to the DVR. 2. Connect the other end of the RCA cable (not included) to the Video Input on the TV if you are using a television screen. 3. If you are using a PC monitor, plug the VGA cable (not included) to the VGA port on the DVR. 4. Connect the other end of the VGA cable to the monitor.
Q-SEE QUICK INSTALLATION GUIDE MODEL NUMBER QR208-811 PART 5 - ACCESSING THE DVR MENUS Choose MENU by right clicking on the mouse or by pushing the MENU button on the DVR front panel or remote control. The Main Menu offers the following Setup Features: CAMERA: Setup name display, position, image view, and record quality of each channel (cameras). RECORD: Enable recording & audio, set resolution & quality, recording mode and file size. NETWORK: Setup Network access (Remote Internet Monitoring).
Q-SEE QUICK INSTALLATION GUIDE MODEL NUMBER QR208-811 Time Schedule Recording: Grid Explanation for Scheduled Recording: Red = Alarm (motion detection) recording Green = General (time schedule) recording Transparent = No recording Blue = The channel and date selected. From the Record Setup screen, set the Rec Mode to “TIME SCHEDULE RECORD” and click “SCHEDULE” in green. This will display the Schedule menu (see below image). Select the channels (cameras) that you wish to record on a schedule.
Q-SEE QUICK INSTALLATION GUIDE MODEL NUMBER QR208-811 The Motion detection Menu has three sections, including Channel Status, Sensitivity and Motion area. STATUS: This option allows you enable motion detection on any channel. SENSITIVITY: This option allows you to set sensitivity level of motion detection from 1 to 4, with 4 being the highest. Next, click on the MD AREA SETUP button, which will display the picture on the left. This option allows you to select the area you want to be sensitive to motion.
Q-SEE QUICK INSTALLATION GUIDE MODEL NUMBER QR208-811 PART 9 - BACKING UP THE VIDEO ON THE DVR Attach a USB flash drive or USB hard drive to the USB backup port and follow the instructions in Part 8 to go to the File List in the Search menu. If you want to backup a single recorded file from the file list, from the File List dialog box pictured above, select the file you wish to back up by placing a check mark in the accompanying green box and hit the [BACKUP] button on the right of the screen.
Q-SEE QUICK INSTALLATION GUIDE MODEL NUMBER QR208-811 Questions or Comments? Contact Us: Mailing Address: Customer Service: DPS, Inc. 8015 E. Crystal Dr. Anaheim, CA 92807 Phone: 877-998-3440 x 538 Email: cs@dpsi-usa.com Live Chat from our Website Website: Tech Support: http://www.q-see.com Fax: 714-998-3509 Phone: 877-998-3440 x 539 Email: ts@dpsi-usa.
