6 – Port Configuration
Displaying Port Information
59183-01 A 6-3
A
6.1.2
Port Operational Information
Enter the Show Port command to display port operational information.
SANbox #> show port 1
Port Number: 1
------------
AdminState Online OperationalState Offline
AsicNumber 0 PerfTuningMode Normal
AsicPort 0 PortID 220000
ConfigType GL PortWWN 20:00:00:c0:dd:07:20:58
DiagStatus Passed RunningType Unknown
EpConnState None MediaPartNumber PL-XPL-VC-SG3-22
EpIsoReason NotApplicable MediaRevision 1
IOStreamGuard Disabled MediaType 400-M5-SN-I
LinkSpeed Auto MediaVendor PICOLIGHT
LinkState Inactive MediaVendorID 00000485
LoginStatus NotLoggedIn SymbolicName Port0
MaxCredit 16 SyncStatus SyncLost
MediaSpeeds 1Gb/s, 2Gb/s, 4Gb/s XmitterEnabled True
ALInit 2 LIP_F8_F7 0
ALInitError 0 LinkFailures 0
BadFrames 0 Login 0
BBCR_FrameFailures 0 Logout 0
BBCR_RRDYFailures 0 LongFramesIn 0
Class2FramesIn 0 LoopTimeouts 0
Class2FramesOut 0 LossOfSync 0
Class2WordsIn 0 LostFrames 0
Class2WordsOut 0 LostRRDYs 0
Class3FramesIn 0 PrimSeqErrors 0
Class3FramesOut 0 RxLinkResets 0
Class3Toss 0 RxOfflineSeq 0
Class3WordsIn 0 ShortFramesIn 0
Class3WordsOut 0 TotalErrors 0
DecodeErrors 0 TotalLinkResets 0
EpConnects 0 TotalLIPsRecvd 0
FBusy 0 TotalLIPsXmitd 4
FlowErrors 0 TotalOfflineSeq 3
FReject 0 TotalRxFrames 0
InvalidCRC 0 TotalRxWords 0
InvalidDestAddr 0 TotalTxFrames 0
LIP_AL_PD_AL_PS 0 TotalTxWords 0
LIP_F7_AL_PS 0 TxLinkResets 0
LIP_F7_F7 0 TxOfflineSeq 3
LIP_F8_AL_PS 0
