4 – Network and Fabric Configuration
Displaying the Ethernet Network Configuration
59183-01 A 4-3
A
4.2
Displaying the Ethernet Network Configuration
The Show Fabric command displays IP addresses (Enet IP Addr) for all switches
in the fabric as shown in the following example.
SANbox #> show fabric
Domain WWN Enet IP Addr FC IP Addr SymbolicName
------ --- ------------ ---------- ------------
16 (0x10) 10:00:00:c0:dd:00:77:81 10.20.68.11 0.0.0.0 gui sb1 .11
17 (0x11) 10:00:00:c0:dd:00:6a:2d 10.20.68.12 0.0.0.0 sw12
18 (0x12) 10:00:00:c0:dd:00:c3:04 10.20.68.160 0.0.0.0 sw .160
19 (0x13) 10:00:00:c0:dd:00:bc:56 10.20.68.108 0.0.0.0 Sb2 .108
The Show Setup System command displays the switch network configuration as
shown in the following example:
SANbox #> show setup system
System Information
------------------
EthNetworkEnable True
EthNetworkDiscovery Static
EthNetworkAddress 10.20.11.32
EthNetworkMask 255.255.252.0
EthGatewayAddress 10.20.8.254
AdminTimeout 30
InactivityTimeout 0
LocalLogEnabled True
RemoteLogEnabled False
RemoteLogHostAddress 10.0.0.254
NTPClientEnabled True
NTPServerAddress 51.68.85.102
EmbeddedGUIEnabled True
