Technical features:
EXTRACTOR FAN STRUCTURE
Model
KH 50 / KH 50 Rustico KH 60 / KH 60 Rustico
Network voltage, V 220 220
Frequency, Hz 50 50
Rated current, А 0,65 0,65
Control Mechanical push-button control
Number of motors, pcs. 1 1
Motor power, W 80 80
Overall power, W 160 160
Performance, cubic m./hour 600 700
Noise level, dB 58 58
Amount of fat filters (five-layer
aluminum), pcs.
2 2
Amount of glow lamps (40W), pcs. 2 2
Air duct diameter, mm 120 120
Dimensions without air duct (WxDxH), mm 500х500х940 600х500х940
Weight, kg 9,5 / 9,7 10,8 / 11
Colour
White / Black / Brown
**
/
Ivory / Stainless steel
**
Construction of the cooking hood
1 – Top decorative casing
2 – Lower decorative casing
3 – Case of the cooking hood with control panel
4 – Decorative roof rail (Optional)
*
5 – Motor
6 – Fat filters
Following is included into delivery set:
• Cooking hood – 1 pc.
• Mounting bar – 1 pc.
• Air duct adapter – 1 pc.
• Installation kit – 1 pc.
• User manual – 1 pc.
• Warranty certificate – 1 pc.
• Box packaging – 1 pc.
* Decorative roof rail is present only in a series of cooker hoods KH Rustico
** Only a series of cooker hoods KH
