PLCMDVR54 DASH CAM Rearview Backup and Driving HD Camera Record Kit 1080p Night Vision Cam Video Recording System
CONTENTS 1 (1) BASIC PARAMETERS ................................................................................................................................. 2 (2) KEY DEFINITION ......................................................................................................................................... 3 1 DVR POWER ON/OFF ...................................................................................................................................4 2 DRIVING RECORD FUNCTION............
BASIC PARAMETERS SPECIFICATIONS ITEMS VALUE Lens 500 million pixels, 140 degree high resolution wide angle lens Lens Aperture F/1.8 Optic 6 glass high-level coating lens+ infrared filter Display 4.3 inch TFT display Recording Resolution 1920x1080@ 30fps, 1280x720@ 30fps Memory Card 4GB/8GB/16GB/32GB/64GB/128GB TF High Speed Memory Card Video Mode Continuous Video, Accident Recording, Parking Video G-Sensor Built-in three-axis G-Sensor, three sensitivity settings level Video Encoding H.
KEY DEFINITION BACK UP CAMERA LCD USB RESET Charging Indicator MIC Recording Light MENU POWER DOWN OK Lens UP Night Lamp Clip on Bracket Speaker Micro SD Slot 3 www.PyleUSA.
1. DVR POWER ON/OFF Startup screen DVR POWER ON • Connect external power supply or press Shutdown screen to turn on the power DVR POWER OFF • Press for 2 seconds, to turn off the power. After setting auto power off time, when there is no external power supply, the system will start the countdown and will shut down when countdown ends. • Low battery will cause automatic power off (3.6V). Notes: Restore factory settings before your first use. Rear view camera will close if there is no external power source.
ICONS Normal Recording 1280x720@ 30fps 1920x1080@ 30fps Sound Recording Off Sound Recording On Prompt Tone On Mute Loop Recording 2 Minutes Loop Recording 1 Minute Full Battery Connect External Power Supply Record Time Emergency Recording Loop Recording 3 Minutes KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to menu Short press Full screen display switch between front camera and rear camera Short pres
ICONS Normal Recording 1280x720@ 30fps 1920x1080@ 30fps Sound Recording Off Sound Recording On Prompt Tone On Mute Full Battery Motion detection recording 10 seconds Record Time Connect External Power Supply Emergency Recording KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to menu Short press Full screen display switch between front camera and rear camera Short press Rear camera display switch Short pr
KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to menu Short press Invalid Operation Short press Invalid Operation Short press Take picture Long press Invalid Operation ok 5. BROWSER FUNCTION DESCRIPTION The number shows the quanTIty of documents contained in the four project folders 'REC Files', 'SOS Files', 'MD Files', 'Photos Files'. Folder with files Folder without files 7 www.PyleUSA.
KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back Short press Left Short press Right Short press Enter Sub-option Long press Invalid Operation ok 5.1 REC FILES REC Files File List FUNCTION DESCRIPTION • Choose the folder and press 'ok' to enter file list. • Press 'ok' again to play the video file.
KEY DEFINITION FOR 'FILE LIST' Key Operation Definition Long press for 2 seconds Shutdown Short press Delete file M Short press Back to REC files folder Short press Up Short press Down Short press Play video file Long press Invalid Operation ok KEY DEFINITION WHEN PLAYING VIDEO FILE Key Operation Definition Long press for 2 seconds Shutdown Short press Invalid Operation M Short press Back to file list Short press Play last video file Short press Play next video fi
FUNCTION DESCRIPTION • Choose the folder and press 'ok' to enter file list. • Press 'ok' again to preview the photos..
SETTINGS KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Invalid Operation Short press Left Short press Right Short press Enter Sub-option Long press Invalid Operation ok 6.1 VIDEO QUALITY VIDEO QUALITY • 1920 X 1080 Frame rate 30fps • 1280 X 720 Frame rate 30fps 11 www.PyleUSA.
KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to menu Short press Up Short press Down Short press Enter sub-option and change setting Long press Invalid Operation ok 6.2 PHOTO SIZE Photo Size setting 1 PHOTO SIZE 14MP(4352 x 3264) 8MP(3264 x 2448) 3MP(2048 x 1536) 1.
KEY DEFINITION FOR 'PHOTO SIZE SETTING 2' Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to previous menu Short press Left Short press Right Short press Confirm setting Long press Invalid Operation ok 6.3 LOOP RECORDING Loop recording 1 Loop recording 2 Loop recording time can be set to 1 minute/ 2 minutes/ 3 minutes for each file. Default setting is 1 minute.
6.4 SOUND RECORD FUNCTION DESCRIPTION • ON: Record video with sound (default setting) • OFF: Record video without sound. KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to menu Short press Up Short press Down Short press Enter sub-option Long press Invalid Operation ok 6.5 AUTO OFF Set auto power off time (10 s, 30 s, 1 minute) when external power source is unplugged. Choose 'OFF' to close this function.
KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to menu Short press Up Short press Down Short press Enter sub-option Long press Invalid Operation ok 6.6 MD SENSITIVITY FUNCTION DESCRIPTION Motion detection sensitivity: HIGH, MIDDLE, LOW.
6.7 COLLISION SENSITIVITY Collision sensitivity: OFF(Default setting), HIGH, MIDDLE, LOW. KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to menu Short press Up Short press Down Short press Enter sub-option Long press Invalid Operation ok 6.8 COLLISION REC TIME After parking the car, if theres a certain intensity of shaking or vibration, the DVR will turn on automatically and start recording.
KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to menu Short press Up Short press Down Short press Enter sub-option Long press Invalid Operation ok 6.9 G-SENSOR OFF/HIGH/MIDDLE/LOW sensitivity for different environment. MIDDLE is the Default setting. KEY DEFINITION Same as 'Collision REC Time' setting. 6.10 BUTTON SOUND • ON: Turn on button sound. • OFF: Turn off button sound. 17 www.PyleUSA.
KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to menu Short press Up Short press Down Short press Enter sub-option Long press Invalid Operation ok 6.11 VOLUME SETTING Volume setting on Mute or 5%-100% KEY DEFINITION Same as 'Button Sound' setting. 6.12 BACKLIGHT TIME • ON: Turn on backlight all the time (Default setting). • 30s: Turn off backlight after no operation for 30s.
KEY DEFINITION Same as above. 6.13 LIGHT FREQUENCY • 50Hz: Remove light frequency interference of 50Hz (Default setting). • 60Hz: Remove light frequency interference of 60Hz. NOTE: This function is to remove the interference of indoor fluorescent light 50Hz or 60Hz to system CMOS image. KEY DEFINITION Same as above. 6.
KEY DEFINITION FOR 'SET CLOCK 2' Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Switch among year, month, date, hour, minute and second Short press Short press + - Short press Confirm setting Long press Invalid Operation ok 6.15 LANGUAGE The system supports English, Simplified Chinese, Traditional Chinese, Korean, Russian, Deutsch, French and Japanese.
6.16 RESET SETUP Initialize all settings to factory default settings KEY DEFINITION Key Operation Definition Long press for 2 seconds Shutdown Short press Turn off backlight M Short press Back to menu Short press Up Short press Down Short press Enter sub-option Long press Invalid Operation ok 6.
7.
INSTALLATION TELESCOPIC BRACKET Telescopic bracket design, four fixed support behind the machine started, alignment rearview mirror bracket can be fixed for each release, Models, simple installa�on and easy disassembly R www.PyleAudio.
BACKUP CAMERA SYSTEMS Angle Adjustable Camera Lens Located on the camera housing are 2 screws which lock the camera lens angle in position. The screws may be loosened to allow camera lens angle adjustment Loosen the screws, adjust the camera lens into the desired angle. then tighten the screws securely. Be sure as to not overtighten the screws. www.PyleUSA.
Model: PLCMDVR54 25 www.PyleUSA.
SYSTEM MESSAGE No SD Card In video recording or camera mode, if the unit does not detect SD card, this picture and voice prompt will appear on screen. Insert SD card, the prompt will disappear and it can start recording or shootting photos. SD Card has no storage space In video recording or camera mode, if SD card has no storage space, this picture and voice prompt will appear on screen and the recording will stop. Clean up SD card. It is suggested to use a special SD card for recording.
