Chapter 3
Additional information
Technical specifications
Inputs Mic 1 to 8 Type Balanced microphone
Connector Female XLR
Sensitivity -6 dB ~ -50 dB
Other 3-Band tone control
Phantom power (48V DC)
Talkover
Channel 1 & 2 Type Unbalanced stereo line
Connector Female RCA (2x)
Sensitivity +4 dB ~ -20 dB
Bluetooth Type Integrated Bluetooth receiver
Mixed with Channel 1
Connector Male SMA connector
Other Included antenna
Front line input Type Unbalanced stereo line
Mixed with Channel 2
Connector 3.5 mm stereo jack
Priority mute contact Type Priority mute
2-pin terminal block ~ 3.81 mm
Outputs Type Balanced stereo line
(2 x for PRE220 - 4 x for PRE240)
Connector 3-pin terminal block ~ 3.81 pitch
Frequency response 20 Hz - 20 kHz
Signal to Noise ratio > 90 dB
Total Harmonic Distortion + Noise < 0.05%
Crosstalk > 70 dB
Controls Front panel control
Bluetooth receiver Bluetooth spec V4.1
Class 2 output power
Indicators Power
Clip (input & output)
Output VU
Power supply Type Switching mode
Range 100-240V~, 50/60 Hz
Power consumption 26 Watt
