Specification Sheet

6200 Maple Avenue / Dallas, Texas / 877-733-8022 / www.purewaterbaths.com Rev04252016
PRODUCT SPECIFICATION
The spa bath shall have an outer dimension of 43
1
/
2
” in width, 71
3
/
8
” in length and 23” in height. Product shall be made of reinforced cast acrylic with a pre-leveled, thermoformed ABS base. The
spa bath jet system shall consist of six (6) Pipeless™ jets with removable jet and impeller assemblies. Product shall be independently certified by NSF International for health and sanitation
characteristics under Protocol P182. The following wetted component parts shall be serviceable and accessible from inside of bathing vessel: control panel, control modules, jet bodies and
motors. The spa bath may be specified with an optional decorative finish drain / overflow, grab bars and ChromaSoothe light(s). Product shall be a Purewater® Baths Serenity with an Elite
Hydromassage System and 6 jet configuration.
NOTE:
Dimensions may vary +/-¼" (7 mm). Service access panel may be required by
local codes.
Model/System Selection
q
Serenity–EliteHydromassageSystem:6Jets
Options and Upgrades
q
ChromaSootheLightingSystemwithcolorwashsetting
and seven solid light colors
m
Single Light System
m
DualLightSystem
q
Decorativefinishcable-operateddrainwithoverflow
m
Polished Chrome
m
OilRubbedBronze
m
BrushedNickel
m
White
m
Biscuit
q
Ergonomicgrabbars:Two12”grabbars
m
White
m
Biscuit
m
Black
q
Colors available
m
White
m
Biscuit
m
Black
Recommended Plumbing Requirements
•WaterSupply:
3
/
4
”N.P.T.
•Drain:1
1
/
2
”O.D.
Water Capacity
Operating70U.S.Gallons(265liters);Min.47U.S.Gallons
(178liters);Max.94U.S.Gallons(356liters)
Electrical Requirements
Hard-wired,115VAC,60Hz,15ampdedicatedcircuit,
GFCIprotected
Shipping
•ShippingDimensions:Width45”(114cm)×Length24”
(61cm)×Height80”(203cm)
•ShippingWeight:203lbs(92kg)
Warranty
•Residential:LimitedLifetimeShell/5-YearPartsLimited
•Commercial:1-YearShell/1-YearPartsLimited
Listings and Certification
Specifiedmodelsmeetorexceedthefollowing:
Specifications subject to changewithoutnotice.
Dimensions/Shape
•Width43
1
/
2
”(111cm),Length71
3
/
8
”(182cm),Height23”(59cm)
•Ovaldesign
Primary Bathing Design
Two-personbath
Installation Types
Drop-inandundermount
Drain Location
Mid-drain
Material
Structurally reinforced cast acrylic
Construction
Self-contained Pipeless™ spa bath mounted on pre-leveled,
thermoformed base
C
NSF Protocol P182
Pipeless™ Hydromassage Jets
660-4472 #2
71 3/8"
43 1/2"
11"
33 1/2"
2"
4 1/2"
23"
46"
19 1/2"
20 1/2"
32"
Control Panel
Drain
Overflow
ChromaSoothe Light
[ 28 cm ]
[ 111 cm ]
[ 58 cm ]
[ 50 cm ]
[ 6 cm ]
[ 53 cm ]
[ 82 cm ]
[ 12 cm ]
[ 86 cm ]
[ 182 cm ]
[ 117 cm ]

