Specifications
■External Dimensions (mm)
PZiG-300/500/700/1000/1300-VTCF-MNPT3/4-V-
150
165
B
A
170
38 32
154154
308
324
170
14
PZiG-300/500/700/1000/1300-FTCT-12 x 15PTFE-W-
165
150
14
170
C
AB
D
E
38 32
170
F
AB
PZiG-300/500/700-VTCF-MNPT3/4-V- 246 49.5
PZiG-1000/1300 -VTCF-MNPT3/4-V- 253 53.5
AB
PZiG-300/500/700-FTCT-12 x 15PTFE-W- 115 97
PZiG-1000/1300- FTCT-12 x 15PTFE-W- 128 128
C
212
256
DE
285 49.5
298 53.5
F
246
253
