Specifications
■External Dimensions (mm)
PZiG-300/500/700/1000/1300-VTCF-VP20-V-
B
A
PZiG-300/500/700/1000/1300-VTCF-FNPT3/4-V-
38
170
32
A
B
165
150
14
294
248
124124
170
AB
PZiG-300/500/700-VTCF-VP20-V- 249 49.5
PZiG-1000/1300-VTCF- VP20-V- 253 53.5
AB
PZiG-300/500/700-VTCF-FNPT3/4-V- 249 49.5
PZiG-1000/1300- VTCF - FNPT3/4-V- 253 53.5
