Specifications
■External Dimensions (mm)
PZiG-300/500/700/1000/1300-VTCE/VTCF-12 x 18PVC-W-
150
165
E
170
3238
D
14
170
C
B
AA
PZiG-300/500/700/1000/1300-VTCE/VTCF-FNPT1/2-W-
D 170
3238
E
14
170
C
B
AA
150
165
AB
PZiG-300/500-VTCE/VTCF-12 x 18PVC-W- 112 224
PZiG-700 -VTCE/VTCF-12 x 18PVC-W- 103 206
C
282
273
AB
PZiG-300/500-VTCE/VTCF-FNPT1/2-W- 100 200
PZiG-700 -VTCE/VTCF-FNPT1/2-W- 90 180
C
270
260
DE
49.5 246
49.5 246
PZiG-1000/1300 -VTCE/VTCF-FNPT1/2-W- 95 190 265 53.5 253
PZiG-1000/1300 -VTCE/VTCF-12 x 18PVC-W- 105 210 275
DE
49.5 246
53.5 253
53.5 253
