Alternative

Power Pumps

for Agriculture

Alternative

Power Pumps

for Agriculture

BULLETIN AGP-09

Neptune’s metering pumps solve your agriculture

and irrigation needs. Neptune offers alternative

powered pumps that provide multiple dosing and

chemical injection solutions using a wide variety

of alternative energy sources.

NEPTUNE’S ALTERNATIVE POWER PUMPS

• Designed for areas without power supply

• Neptune Series 500 and 7000 pumps can be powered by hydraulic motors

using fluid pressure from the hydraulic system in hydraulically powered

center pivots

• Belt driven pump can be adjusted without shutting down irrigation engine

• The 12 volt pump is provided with clamps to connect directly to the

irrigation engine battery

• Neptune Series 7000 pump with gas engine and trailer mounted chemical

supply tank allows the rig to travel directly to the area requiring injection

• Solar installation low power draw allows a minimum solar collector array

to perform very well in a variety of latitudes

ALTERNATIVE

POWER SOURCES

• Belt drive

• Solar powered

• Hydraulic motor powered

• 12 volt

• Gasoline motor

Neptune Series 7000

belt driven

Neptune Series PZ

PAGE 1
BULLETIN AGP-09 Alternative Power Pumps for Agriculture Neptune’s metering pumps solve your agriculture and irrigation needs. Neptune offers alternative powered pumps that provide multiple dosing and chemical injection solutions using a wide variety of alternative energy sources.
PAGE 2
PZ PUMP Tech • Manual, 4-20 mA or water pulse controlled • Available in PVC, Acrylic and Kynar • Automatic degassing valve option Features • Operates from 94 VAC to 264 VAC • Manual stroke length adjustment 50 to 100% • Manual and automatic stroke speed adjustment • External interlock available • Repeat cycle and counter functions built in Performance • 0.5 ml per stroke/min.; 1300 ml/min.
