PARAMETERS OF THE SWITCH
Ports
16 x PoE (10/100 Mb/s) (RJ-45)
2 x UPLINK (10/100/1000 Mb/s) (RJ-45)
2 x UPLINK (10/100/1000 Mb/s) (SFP)
with connection speed auto-negotiation and MDI/MDIX Auto Cross)
PoE power supply
IEEE 802.3af/at (1÷16 ports), 54V DC / 30W at each port *
Used pairs 4/5 (+), 7/8 (-)
Protocols, Standards
IEEE802.3, 802.3u, 802.3x CSMA/CD, TCP/IP
Bandwidth
14,8 Gbps
Transmission method
Store-and-Forward
Optical indication of
operation
Switch power supply;
Link/Act;
PoE Status
Mains supply
230V AC (-15%/+10%) / 50Hz
Current up to
1,3A max. / 230V AC
Supply power
219W
Output current at the PoE ports (RJ45)
16 x 0,6A ΣI=4A (max.)
Output voltage at the PoE ports (RJ45)
54V DC
PSU current consumption
250mA
Battery charge current
(batteries 4x7Ah / 4x17Ah, connect
batteries in series)
0,5A max. /4x12V (+/-5%)
Approximate backup time
5h 15min
Battery circuit protection SCP and
reverse polarity connection
melting fuse
Deep discharge battery protection UVP
U<38V (± 5%) – disconnection of the batteries
* The given value of 30W per port is the maximum value. The total power consumption should not exceed 192W when all PoE ports
are being used.
ELECTRICAL PARAMETERS
MECHANICAL PARAMETERS
Mounting dimensions
W=19”, H=2U, D=348
Dimensions
W=482, W
1
=446, H=88, D=348, D
1
=32, D
2
=15 [+/- 2mm]
Fixation
four-point butt mounting to RACK profiles – the set include 4 M6 screws + cage nuts
Gross/Net weight
5,6 / 6,5 kg
Enclosure
Steel plate, DC01 1,0mm color: black RAL 9005
Connectors
Power supply of the cameras: RJ45 socket
Output of recorder: RJ45 socket or SFP
Outputs: Φ 0,63-2,50 (AWG 22-10), battery output BAT: 6,3F-2,5
Notes
Forced cooling (fan).
s RSFUPS116 16-port switch with buffer power supply
for 16 IP cameras, RACK mounted
