Data Sheet

Accessories for cabinets - Patch Panel
Pulsar
®
RP-F24V6 v1.0/I
Patch Panel RP- 24V 24 ports / TP / Cat
F 6 F 6
CODE
NAME
:
:
APPLICATION
Fundamental element of telecommunication networks. It is the final element of the structured
network cabling. The model designed for Cat 6 FTP cables.
Patch Panel is fitted with 24 ports.
Tel. [phone], Fax. [phone], www.pulsar.pl, e-mail: [e-mail]
EN
TECHNICAL DATA
Patch panel type
24 ports / FTP / Cat6
Mounting dimensions:
W=19”, H=1U
External dimensions:
W=482 H=44 D=110 [mm, +/-2]
Net/gross weight:
1,55/1,65 [kg]
Finish:
- steel plate 1,2 mm, color black (RAL 9004)
Notes:
- LSA connector strip, mounted horizontally – easy installation (punch down tool in vertical
position)
- Patch panel is fitted with mounting shelf allowing mounting and routing cables
- additional metal cable clips for each twisted pair
- ground wire/wire end included
- descriptions and numbering of each RJ45 connector at the front panel
- graphic indication of cable connectors (568A/B standard)
- four-point front mounting to RACK profiles
- the set includes 4 M6 screws + cage nuts + cable ties
465
440
110
1U
44
19"
