User Instructions

www.pulsar.pl ROUPS12VR RACK POWER CCTV
5
Electrical parameters (tab. 2).
Mains supply
176÷264V AC
Current up to
0,8A@230V AC max.
Supply power
74W max.
Efficiency
71%
Output voltage DVR - recorder
12V DC
Output current
5A recorder + 1A battery charge
Ripple
50 mV p-p max.
Battery charge current
(batteries 1×7Ah / 1x17Ah / 1x28Ah)
1A max. (+/-5%)
Short-circuit protection SCP
F 5A, melting fuse
Overload protection OLP
Current consumption by PSU systems
105% ÷ 150% of the PSU power, automatic return
0,2A
Overvoltage protection OVP
>16V (activation requires disconnecting the load or supply for
about 20s.)
Battery circuit protection SCP and reverse
polarity connection
polymer fuse PTC
Surge protection
varistors
Excessive discharge protection UVP
U<9,5V (+/-5%) – disconnect of connection battery
Optical indication of operation:
LED: AC, DC, TEMP, LoB, ALARM, DVR
Acoustic operation indication:
Piezoelectric indicator ~75dB/0,3m
The ALARM technical output of collective
failure
Relay type: 1A@ 30VDC/50VAC
The F
MAINS
fuse in the 230V power supply
circuit
T 3,15A
F
DVR
fuses in the recorder power supply
circuits AUX(+)
F 5A
Mechanical parameters (tab. 3).
Enclosure dimensions
W=19”, H=2U; 482 x 88 x 223 mm (WxHxD)
Fixation
four-point butt mounting to RACK profiles – the set include 4 M6 screws + cage nuts
Net weight
5,50kg / 5,80kg
Enclosure
Steel plate RAL 9005, black
Connectors
230V AC input: the IEC C14 socket with a fuse, power cable 2m
(included)
Outputs: ALARM, BAT: Φ0,5-2,1 (AWG 24-12) 0,5-1,5mm
2
Output DVR: Φ0,5-2,1 (AWG 24-12) 0,5-1,5mm
2
, power cable 2m
(included)
Battery output BAT: 6,3F-2,5
Notes
Forced cooling (fan).
Operation safety (tab.4).
Protection class PN-EN 60950-1:2007
I (first)
Protection grade PN-EN 60529: 2002 (U)
IP20
Electrical strength of insulation:
- between input and output circuits of the PSU (I/P-O/P)
- between input circuit and PE protection circuit (I/P-FG)
- between output circuit and PE protection circuit (O/P-FG)
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
Insulation resistance:
- between input circuit and output or protection circuit
100 MΩ, 500V/DC
Operating parameters (tab.5).
Environmental class
II
Operating temperature
-10ºC...+45ºC
Storage temperature
-20ºC...+60ºC
Relative humidity
20%...90%, without condensation
Vibrations during operation
unacceptable
Impulse waves during operation
unacceptable
Direct insulation
unacceptable
Vibrations and impulse waves during transport
According to PN-83/T-42106
